6300W Desktop Solder Reflow Oven 310 ℃ Tablet With Dual Core CPU
6300W Desktop Solder Reflow Oven 310 ℃ Tablet With Dual Core CPU
6300W Desktop Solder Reflow Oven 310 ℃ Tablet With Dual Core CPU
6300W Desktop Solder Reflow Oven 310 ℃ Tablet With Dual Core CPU
Specifications
Brand Name :
YUSH
Model Number :
YS-301N
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
USD2500
Payment Terms :
L/C, D/P, D/A, Western Union, T/T, MoneyGram
Supply Ability :
50sets/month
Delivery Time :
5-7 work days
Packaging Details :
plywooden case
Applicable fusion welding type :
Lead free and leaded solder paste
PCB tray size :
350 mm x 240 mm
Effective fusion welding range :
250 mm x 200 mm
Type of heating element :
Infrared quartz heater + forced hot air return
Heating capacity range :
Ambient temperature - 310 ℃
Display panel unit :
7 "high resolution LCD touch screen
Description

YS-301N Desktop Reflow Oven

350 mm x 240 mm 310 ℃ Tablet with dual core CPU YS-301N Desktop Solder Reflow Oven

Desktop Solder Reflow Oven 350 Mm X 240 Mm 310 ℃ Tablet With Dual Core CPU

1.Description:

YS-301N, a revolutionary new generation product, is a desktop miniaturized structure with a built-in automatic temperature processing feedback system, so that users can easily achieve perfect fusion welding when putting the first PCB, and can completely follow the user specified fusion welding process flow: preheating, melting tin, reflow, cooling, the whole process in one go.

6300W Desktop Solder Reflow Oven 310 ℃ Tablet With Dual Core CPU

2.Technical Parameters:

Applicable fusion welding type Lead free and leaded solder paste
PCB tray size 350 mm x 240 mm
Effective fusion welding range 250 mm x 200 mm
Type of heating element Infrared quartz heater + forced hot air return
Heating capacity range Ambient temperature - 310 ℃
Temperature control system Real time temperature PID closed-loop feedback system in accordance with lead-free specification
Preheating time About 2 mins
Control computer unit Tablet with dual core CPU
Display panel unit 7 "high resolution LCD touch screen
Temperature control settings: Fast and intelligent programming based on temperature rise rate curve (degree / second)
Temperature characteristic display Real time temperature characteristic curve of automatic drawing
Temperature curve printing Printing temperature characteristic curve through WiFi connection
Expand storage External memory can be used through WiFi connection
Rated voltage 220V single-phase alternating current, 50 / 60Hz, average 15a, peak 30A
Efficiency: 6300W
Machine size: 690 mm L x 470 mm W x 270 mm H
Machine weight 68KG

6300W Desktop Solder Reflow Oven 310 ℃ Tablet With Dual Core CPU

3.Features:

1. A real-time temperature PID closed-loop feedback system corresponding to lead-free characteristic curve.

2. Rapid and intelligent compilation of temperature rise rate curve.

3. Perfect lead-free fusion welding with infrared and hot air convection.

4. Direct display of real-time temperature curve.

5. Multi core CPU and Android system platform.

6. 7-inch high-resolution LCD display, full touch.

7. Compact fuselage design for laboratories, schools, engineering models, and small-scale production environments.

8. Backup storage and printing of connected data can be done through WiFi.

6300W Desktop Solder Reflow Oven 310 ℃ Tablet With Dual Core CPU
