2 Linear Blades PCB Depaneler Equipment Optional 130-600mm Cutting Length
2 Linear Blades PCB Depaneler Equipment Optional 130-600mm Cutting Length
Specifications
Brand Name :
Winsmart
Model Number :
SMTPD2
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
USD1-10000/set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 sets per month
Delivery Time :
2-5 days
Packaging Details :
Plywood case
PCB Type :
V-cut
Cutting Length :
130-600mm
PCB Material :
FR1, FR4, CEM, MCPCB
Cutting Stress :
Less than 400ustrain
Test Report :
Provided
Name :
PCB Depaneler Equipment
Description

2 Linear Blades PCB Depaneler Equipment Optional 130-600mm Cutting Length

PCB Depaneler Usage Industry:

SMT/EMS, military industry, automotive, semiconductor, medical, communication, 3C, white goods, LED, circuit board, etc.

PCB Depaneler Overview:

This equipment is designed to minimize board stress and avoid component damage.

Heavy frame for stability, pneumatic cylinder operated.

PCB Depaneler Features:

1. Dual V shape blades for a perfect board cut without bending or tension.

2. Pneumatic footpedal control.

3. Small clearance between upper and lower blades to ensure safety operation.

4. The system only allows correct board placement to avoid mistakes.

5. Separate boards safely with parts as close as 0.5mm to the score line, including ceramic capacitors.

6. Compressed air as power, clean and low cost.

7. Customized blades are available.

8. Customized tray for easier handling is available.

PCB Depaneler Specification:

Model SMTPD2　
Machine Dimension 720x300x440mm / 520x300x440mm / 500x300x440mm
Max Cutting Length 330mm / 200mm / 130mm
PCB Material FR4, MCPCB, CEM, Copper Boards
Air Pressure 0.4-0.7MPa
PCB Thickness 0.3-3.5mm
Power 110/220V
Machine Weight 130kgs / 100kgs / 80kgs
