Steel Tin Pluggable Terminal Blocks PA66 Brass M2.0 Zinc Plated JL15EDGK
Steel Tin Pluggable Terminal Blocks PA66 Brass M2.0 Zinc Plated JL15EDGK
Specifications
Brand Name :
JILN
Model Number :
JL15EDGK
Certification :
UL/CUL/Rosh/SGS
Place of Origin :
China
MOQ :
1000PCS
Price :
0.01-1USD
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30000000PCS per Month
Delivery Time :
7-10 days
Packaging Details :
Tube packing/PE bag packing
Insulator Material: :
PA66
Rated Current :
300V,8A
Withstand Voltage :
1500V AC/DC
Insulation Temperature :
-40℃~+105℃
Name :
Terminal Block Connector
Pitch :
5.08mm Pitch
Description

5.00 5.08mm Pitch M2.0 Zinc Plated Green Pluggable Terminal Blocks JL15EDGK AC2000V PA66

Specifications:

Rated Currency: 300V,8A
Dieletric Strength: AC2000V/1 Minute
Insularion Resistance: 500mΩ Min
Contact Resistance: 20mΩ Max
Screw Torque: 0.2N.m 1.7Lb.in
Wire Range: 28-16AWG
Strip Length: 5-6mm
Term. Range: -40℃~+105℃
Max Solering +250℃.5S
Housing Material: PA66(UL94 V-O)
Contact: Steel, Tin Plating
Clamp: Brass/Steel, NI Plating
Wire Protector: Brass,Ni Plating
Screw: -

Company History:

In November,2008, The company has awarded three products patents and rated as excellent enterprise in Shenzhen.

In September,2010, The com pany was awarded”Guangdong’s Excellent Proprietary Brand” by Guangdong Entrepreneurs Association.

Our business concept:integrity,gratitude and responsibility.

Our business strategy:quality first,customer first,excellence,team work!

Our service philosophy:speed,precise,considerate,carefully,elaborately,diligently.

Quality control process

We place strong emphasis on quality of out products and service, with a stringent quality assur-ance system in each operation process, we also service with strict inspection and control finished product. We believe in continuing education and invest in training programs for out employees. Mainly out management and engineering staff, in order to maintain a productive workforce and keep pace with new Changes in technology..Outstanding quality is the basis of brand, satisfying service is the guarantee of brand, perpetual innovation is the soul of brand
