We provide OEM one-stop PCBA assembly services designed specifically for medical device manufacturers, offering a comprehensive solution that ensures every step meets the stringent requirements of the medical industry. From design and prototyping to mass production, assembly, and testing, we adhere to the highest standards, including ISO 13485, to guarantee safety, precision, and reliability.

Our production processes are tailored to meet the unique demands of medical devices:

1. High-Precision Manufacturing – Utilizing advanced equipment and strict quality control systems, we ensure the accuracy of every solder joint and component placement, which is critical for devices like patient monitors and diagnostic equipment.
2. Specialized Processes – We focus on low-power optimization, miniaturization for compact devices, and thermal management to support the stability and longevity of medical electronics.
3. Rigorous Testing Protocols – Our process includes functional testing, reliability testing, and environmental stress testing to ensure the PCBA performs consistently under real-world medical conditions.

With an optimized production workflow, traceability systems, and flexible customization options, we are equipped to handle both small-batch prototypes and large-scale production with efficiency. By combining cutting-edge technology, expert craftsmanship, and a deep understanding of the medical industry's regulatory requirements, we deliver PCBA solutions that enable your medical devices to achieve exceptional performance, reliability, and patient safety.

Partner with us to bring innovation and precision to your medical devices, helping you stay ahead in a competitive and evolving healthcare market

We support our Customers at each stage of the product life cycle

Pick & Place Technical Capabilities

• High-speed, software-controlled pick&place machines
• YoM: 2016 or higher

Pick & Place:

• From 01005 competent size
• From 12 Pitch
• BGA and Mini BGA
• Pin In Paste
• PoP – package on package
• Stack (MA) Matrix Tray
• Paste & Glue

Reflow:

• 2 Sided SMT Reflow
• Nitrogen SMD Reflow
• High temperature
• Pb and Pb free

Soldering Technical Capabilities

Screen Printing:

• Step Stencil (Cross Over)
• Pb and Pb free

Soldering:

• No Clean Process
• Lead-Free Hi Temperature
• Nitrogen Wave
• Spray Flux Application
• Nitrogen Reflow
• Soldering Point
• Manual Soldering
• Pb and Pb free

Inspection & Test Capabilities

Inspection:

• 2D & 3D Inline Automated Optical Inspection (AOI)
• 3D Automated X-Ray (AXI)
• 3D Automated Solder Paste
• Cross Section
• Coordinate Measuring Machine
• Manual Visual Inspection
• Test:

Functional Test

• In-circuit test (ICT)
• Environmental tests (Thermal Shock Chamber)
• Burn-In Test
• High VoltageTest
• Stress Test
• Strain tests
• Leakage test

Conformal Coating & Potting

Assembly Cleaning

Conformal Coating:

• ASYMTEK Select Coat® SL-940 Series conformal coating system for inline production
• Film coater SC-104 with rotate options
• Precision head available
• Laser Fan Width Control
• UV system control
• Curing

Potting:

• 2 applications valid for two different compounds
• Repeatable process: electronically controlled dozing
• Different types of materials (Epoxy, Polyurethane, Silicones)

General Capabilities

Software:

• Manufacturing Execution System (MES) - incl. traceability
• Production Planning integrated with MES and ERP
• Documentation Management: M-Files
• ERP: Microsoft Dynamics AX
• EDI & API information exchange
• Marking: Automatic label & Laser marking systems
• Depanelling: Router / V-cut / Punch
• Production Equipment: Assembly lines & assembly cells design & build
• Milling & Drilling: Working area 740 x 740 x 150 mm
• Problem-Solving: Failure Analysis & Troubleshooting
• BGA/LG Rework (balling & rebilling)
• Programming: serial Flash programming

Product Packaging:

The EMS PCB Assembly product will be packaged securely in anti-static bags and placed in a sturdy cardboard box with protective foam inserts.

Shipping:

We offer worldwide shipping for the EMS PCB Assembly product. Shipping options include standard, expedited, and express delivery. Customers can choose their preferred shipping method during the checkout process.

All shipments will be tracked and customers will receive a tracking number once the product has been shipped. Shipping fees will be calculated at checkout based on the destination and selected shipping method.

FAQ:

Q1: What service do you have?
XHT: We provide turnkey solutions including PCB design, Software development, PCB Assembly, Enclosure design, Mold-making, Plastic injection, Finish product assembly, and function testing.
Q2: What are the main products of your PCB/PCBA services?
XHT: Our PCB/PCBA services are mainly for industries including Industrial control, Home appliances main boards, automotive electronics, Consumer electronics, Medical equipment, bank equipment, smart home, etc.
Q3: Is XHT a factory or trade company?
XHT: XHT is a 20-year experienced professional contract manufacturer to provides a stop Turnkey PCB assembly and electronics manufacturing service.
Q4: Can we inspect quality during production?
XHT: Yes, we are open and transparent on each production process with nothing to hide. Customers are welcome to inspect our production process and check in-house.
Q5: How can we ensure our information should not let the third party see our design?
XHT: We are willing to sign an NDA effect by customer side local law and promise to keep customers' data in high confidential level.
Q6: What files are required to get a quotation from you?
XHT: For OEM PCBA projects, please provide the Gerber data/files and an indication of related technical requirements as well as any special requirements if you have them; For ODM projects, please provide a Function List, so our engineering team can work on it.
Q7: What is the standard delivery term?
XHT: Delivery terms of EXW, FCA, FOB, DDU, etc. are all available based on each quote.
Q8: How long does it take for a PCBA quote?
XHT: Depends on the project's complexity. Normally 1-2 weeks is enough for our engineers to evaluate.
Q9: Do you have any minimum order quantity (MOQ) requirements?
XHT: No, we do not have MOQ requirements, we can support your projects starting from prototypes to mass productions.
