Stand Alone KAVO Spindle PCB Router Machine with CE Certification
Stand Alone KAVO Spindle PCB Router Machine with CE Certification
Stand Alone KAVO Spindle PCB Router Machine with CE Certification
Stand Alone KAVO Spindle PCB Router Machine with CE Certification
Specifications
Brand Name :
Chuangwei
Model Number :
CW-F01-S
Certification :
CE ISO
Place of Origin :
Dongguan
MOQ :
1 Set
Payment Terms :
T/T, L/C,paypal
Supply Ability :
300 sets per month
Delivery Time :
1-3 days after payment confirm
Packaging Details :
each set be packed in carton boxes
Price :
Negotiable
Work area :
320*320mm
Table :
2
Warranty :
one year
PCB thickness :
0.5-3.5mm
Spindle speed :
60000RPM
Description :
PCB Router Separator
Description

Stand Alone KAVO Spindle PCB Router Machine with CE Certification

It is a stand alone router machine specially designed to route (depanelize) printed circuit board assemblies (PCBA) into individual assemblies. The machine can accomodate larger PCBs in its two table configuration with maximum panel size of 650mm x 500mm. Its advanced control software provides user friendly "visual" programming for rapid and accurate online programming.

Feature:

Large range of panel size up to 650 mm x 500 mm

Powerful servo motors powered axis

CE Certification (Option) Dual Vacuum Blow

Specification:

Model CW-F01-S
Standard working area 320*320mm
Power 220V, 4.2KW
Manipulator Repeatability ±0.02mm
Resolution ±0.01mm
Board Positioning Dual workstation with nest fixture or pin fixture
Panel Location Located by tooling holes or edges of PCB
Loading Manual
Unloading Manual
Panel Size 320*320mm(standard)
Panel Thickness 0.5-3.5mm
Spindle motor 0.5kW Morning Star Spindle
Tool Change Manual
Dust filtration system 3KW Vacuum Cleaner
Vision system High resolution CCD video camera
Programming Vision assisted point to point manual teaching
Editing Function Dry run vision assisted / test run mode
Machine weight 500kgs
Machine dimension 113*140*108cm

Stand Alone KAVO Spindle PCB Router Machine with CE Certification

More information welcome to contact us:

Email/Skype: s5@smtfly.com

Mobile/Wechat/WhatsApp: +86-136-8490-4990

Contact: Bunny
