Pitch 10mm Type Barrier Terminal Block 20A Plastic Black 2 Poles
Pitch 10mm Type Barrier Terminal Block 20A Plastic Black 2 Poles
Specifications
Brand Name :
SCED
Model Number :
TB1000-05-C
Certification :
CE,UL,CUL,CQC,VDE etc.
Place of Origin :
Guangdong, China
MOQ :
500 Piece/Pieces
Price :
USD 0.127-0.203 Per Pole
Payment Terms :
T/T, L/C
Supply Ability :
1000000 Pole/Poles per Month
Delivery Time :
5-20 days
Packaging Details :
Packaging Details: Standard export packing carton, or according to customers demand; Normally, one master carton packs 16 inner boxes inside, but some items maybe different due to the products dimensions. Standard Master Carton Dimension: 341 x 273 x 198
Plastic :
PBT
Inflammability Class :
UL94,V0
Voltage :
300V
Current :
20A
Type :
Barrier
Terminal :
Brass
Poles :
2 poles
Rated Surge Voltage :
No abnormal within 1 minute
Insulation Resistance :
Above DC500V, 500MΩ
Contact Resistance :
Less than 8mΩ
Description

Pitch 10mm Barrier Terminal Block 300V 20A Brass Plastic Black

Detailed product Description:

Pitch 10.00mm, 300V 20A, 2P, Barrier Terminal blocks, power terminal block

■ Right angle wire inlet; □Vertical wire inlet; □45 degree wire inlet

■ Single Level; □Double levels; □Triple levels

Standard color: Black. Other colors also available.

Applications:

PCB, Frequency Converters, Server Site, Switch, Power Supply, Electric Lighting, Industry Control, Automation, Rail Transportation, Communication, Electric Power, Security, Medicine Equipment, Military, Elevator, etc..

 'o�/� �h� :"Verdana","sans-serif";mso-bidi-font-family:Verdana'>

■ Right angle wire inlet; □Vertical wire inlet; □45 degree wire inlet

■ Single Level; □Double levels; □Triple levels

Standard color: Black. Other colors also available.

Parameter and Drawing Specifications:

UL Technical Data

B

C

D

Rated Voltage / Current V/A

300 / 20

300 / 10

Wire Range AWG

10-18

10-18

IEC Technical Data

Overvoltage Category

Ⅲ

Ⅲ

Ⅱ

Contamination Class

3

2

2

Rated Voltage / Current V/A

500 / 41

600 / 41

800 / 41

Rated Surge Voltage KV

6

6

6

Rated Connecting Capacity mm2

6

Material

Insulation Material / Inflammability Class

PBT / UL94, V-0

Terminal / Plating

Brass /Tin Plated

Screw / Plating

Steel / Nickel Plated

Other Data

PCB Hole Diameter mm

φ2.0

Stripping Length mm

9-10

Screw / Torque / lbf.in

M 4 / 10-13

Competitive Advantage:

  1. Stable good quality
  2. Competitive price
  3. Quickly response
  4. Full range products for selection
  5. Flexible to design the exact part per customers’ demand.Pitch 10mm Type Barrier Terminal Block 20A Plastic Black 2 Poles
