Product Description:

The PCD grinding machine is a highly efficient tool designed specifically for grinding PCD/PCBN materials. It is equipped with advanced features to ensure precision and accuracy in grinding operations.

One of the key attributes of the PCD grinding machine is its Optical Tube Distance of 300mm, which allows for clear visibility and precise control during the grinding process. This feature enables operators to monitor the grinding operation closely and make necessary adjustments for optimal results.

The Pixel Size of the PCD grinding machine is 3.75um*3.75um, ensuring fine and detailed grinding of PCD/PCBN materials. This precise pixel size contributes to the overall quality and consistency of the grinding results, making the machine suitable for various industrial applications.

With a Tip Radius ranging from 0 to 70mm, the PCD grinding machine offers versatility in grinding different workpieces and achieving various grinding profiles. Whether working on small or large components, operators can easily adjust the tip radius to meet specific requirements and produce high-quality finishes.

The Size of Cross Table on the PCD grinding machine is 210*160mm, equipped with 4T grooves for securing the workpiece during grinding. This robust cross table provides stability and support for the workpiece, ensuring accurate and uniform grinding results. The grooves further enhance the gripping capability of the table, preventing slippage and maintaining workpiece alignment.

Featuring a Readout of Linear Gratings at 0.001mm, the PCD grinding machine offers precise measurement and control of the grinding process. This high level of accuracy allows operators to monitor the grinding parameters closely and make real-time adjustments for optimal performance. The readout system ensures consistency and repeatability in grinding operations, contributing to overall efficiency and quality.

In summary, the PCD grinding machine is a versatile and reliable tool for grinding PCD/PCBN materials with precision and efficiency. Its advanced features, including the Optical Tube Distance, Pixel Size, Tip Radius adjustment, Size of Cross Table with 4T grooves, and Readout of Linear Gratings, make it a valuable asset for various grinding applications. Whether used in manufacturing, tooling, or other industries, the PCD grinder delivers consistent and high-quality grinding results, meeting the demands of modern production processes.

Applications:

CTSTC PCD Grinding Machine is a high-precision equipment designed for grinding hard materials, specifically PCD/PCBN tools. With its exceptional performance and innovative features, this product is suitable for various application occasions and scenarios:

- Manufacturing plants: The PCD Grinding Machine is ideal for manufacturing plants involved in producing cutting tools, drills, and other precision components made from hard materials. Its ability to grind PCD/PCBN tools with precision and efficiency makes it a valuable asset in enhancing production quality.

- Tool and die shops: Tool and die shops can benefit from the CTSTC PCD Grinding Machine for sharpening and regrinding PCD tools used in metalworking, woodworking, and other industries. The machine's grinding wheel height adjustment of 140mm and adjustable grinding pressure of 0-450N ensure precise and consistent results.

- Research and development facilities: Research and development facilities working with advanced materials can utilize the PCD grinder to maintain and sharpen PCD tools with utmost accuracy. The cross table swiveling angle of 270° allows for versatile grinding operations, catering to a wide range of tool geometries.

- Industrial maintenance workshops: Industrial maintenance workshops dealing with heavy-duty tools and components can rely on the CTSTC PCD Grinding Machine for efficient material removal and surface finishing. The machine's robust construction and net weight of 1450kgs ensure stability and durability during operation.

With a pixel size of 3.75um*3.75um, the PCD Grinding Machine delivers precise and detailed grinding results, meeting the demands of high-precision applications. It comes with CE certification, guaranteeing compliance with quality and safety standards.

Customers can place orders for the PCD Grinding Machine with a minimum order quantity of 1 unit. The product is securely packaged in a plywood box to prevent damage during transit. Delivery time is estimated at 45-60 days from the date of order, and payment terms accepted include TT, LC, and Western Union.

Customization:

Product Customization Services for the CTSTC PCD/PCBN Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Dimension: 1200*1168*1530mm(L*H*W)

Tip Radius: 0-70mm

Name: PCD/PCBN Grinding Machine

Image Magnification: 45-250 Times(digital Zoom)

Spindle Speed: 0-42000RPM(adjustable)
