Specifications
Brand Name :
Halnn
Model Number :
CNMN120412
Certification :
ISO9001
Place of Origin :
China
MOQ :
10 pcs
Price :
Negotiable ( About 10-30 Usd/ Piece)
Payment Terms :
T/T, Western Union, MoneyGram,Paypal
Supply Ability :
100000 pcs per month
Delivery Time :
3~15 working days
Packaging Details :
10 pcs in one plastic box inside, carbon box outside
Machining Process :
Heavy turning
Dimension :
Customter-made
Application :
Pump
Origin Country :
Henan,China
Mnchining Material :
High Chromium Cast iron
Brade :
Turning Tools
Insert Garde :
CNMN120416
Body :
Cubic boron nitride
Coating :
Uncoated
Grade :
ISO Grades
Description

Large working allowance High Speed Machining Slurry pump cutting tools with CBN Cutting Tools​

1. Halnn Tools Large working allowance High Speed Machining Slurry pump cutting tools with CBN Cutting Tools​

Carbide Insert has low hardness, when machining industry pump with carbide insert, it needs to change the insert frequently, which will affect the production efficiency and the surface quality. Ceramic Cutters has large brittle, so rough machining process can’t use ceramic cutters. CBN Inserts will be the right choice for rough machining pumps. The hardness of cbn insert is only second to diamond tools, and mainly used for machining ferrous metal materials, especially Halnn BN-K1 solid cbn insert is researched for rough machining high chromium cast iron and already is widely used in high chromium cast iron industry.

2. CBN Cutting Tools Characteristics

Insert Grade Machining Type Hardness(HV) Binder
BN-K1 Roughing 3000-3250 TIC
BN-S20 Roughing, Semi-Finishing 2900-3100 TIN

3.Detailed Data of CBN Cutting Tools

Large Working Allowance Cbn Cutting Tools High Speed Machining Slurry Pump Cutting Tools
Type Dimension Standard Chamfer Grades Corresponding tool holder
L(mm) φI.C(mm) S(mm) r(mm) BN-K1 BN-S20
CNMN120412 12.9 12.7 4.76 1.2

S01020

S01025

S02020

S02030

S02530

S03020

 ● ● CCLNR/L
CNMN120704 12.9 12.7 7.94 0.4 ● ●
CNMN120708 12.9 12.7 7.94 0.8 ● ●
CNMN120712 12.9 12.7 7.94 1.2 ● ●
CNMN120716 12.9 12.7 7.94 1.6 ● ●

4.Packing of CBN Cutting Tools

Large Working Allowance Cbn Cutting Tools High Speed Machining Slurry Pump Cutting Tools

5.Application Case of High Speed Machining Slurry pump cutting tools with CBN Cutting Tools​

Large Working Allowance Cbn Cutting Tools High Speed Machining Slurry Pump Cutting Tools

6.FAQ

Q1. Do you have different quality for different kind of stone?

A1. Yes, according hardness of stone and stone’s feature, we have different typology respectively.

Q2. If we need technical support, can you offer us?

A2. Yes, we have an experienced team, offering our customers additional benefits with specific advice, by our product managerment staff, engineers and technicians.
