Specifications
Brand Name :
Halnn
Model Number :
SNMN120712
Certification :
ISO9001
Place of Origin :
China
MOQ :
10 pcs
Price :
Negotiable ( About 10-30 Usd/ Piece)
Payment Terms :
T/T, Western Union, MoneyGram,Paypal
Supply Ability :
100000 pcs per month
Delivery Time :
3~15 working days
Packaging Details :
10 pcs in one plastic box inside, carbon box outside
Machining Process :
Processing
Dimension :
Customter-made
Application :
Mud pump
Origin Country :
Henan,China
Mnchining Material :
High Chromium Cast iron
Brade :
Halnn Tools
Insert Garde :
SNMN120712
Body :
Cubic boron nitride
Coating :
Uncoated
Grade :
ISO Grades
Description

Large working allowance machining CBN Cutting Tools for rough Machining Mud pump CBN Tools​

1. Halnn Tools Large working allowance machining CBN Cutting Tools for rough Machining Mud pump CBN Tools​​

The problems of difficult to machine pumps:

(1) The material of industry pump is high chromium cast iron, the hardness after castings is high, traditional cutting tools can’t machine.

(2) The working allowance is large, and it also have some defects, such as sand, hard pot, it will require high on the wear resistance and impact resistance.

(3) Machining industry pump belong to interrupt turning condition, however traditional cutting tools can’t use.

2.Pictures of Halnn Tools CBN Cutting Tools

High Chromium Cast Iron CBN Cutting Tools / Cbn Milling Inserts SNMN120712

3. CBN Cutting Tools Characteristics

CBN Grade Hardness(HV) Binder CBN Content(%) Granularity(μm)
BN-K1 3000-3250 TIC 90 8-12
BN-S20 2900-3100 TIN 76 4-6

4.Detailed Data of CBN Cutting Tools

High Chromium Cast Iron CBN Cutting Tools / Cbn Milling Inserts SNMN120712
Type Dimension Standard Chamfer Grades Corresponding tool holder
L(mm) φI.C(mm) S(mm) r(mm) BN-S20 BNK30 BN-S300
SNMN120412 12.7 12.7 4.76 1.2

S01020

S01025

S02020

S02030

S05020

S10020

 ● ● ●

CSDNN

CSSNR/L

CSKNR/L

CSRNR/L

CSXNR/L
SNMN120712 12.7 12.7 7.94 1.2 ● ● ●
SNMN120716 12.7 12.7 7.94 1.6 ● ● ●

5.Application Case of Large working allowance machining CBN Cutting Tools for rough Machining Mud pump CBN Tools​

Common model insert model for machining industry pump: SNMN120712,SNMN120708, CNMN120412,SNMN120412, it can replace carbide insert, ceramic cutters and common cbn insert Common tool holder model for machining industry pump: CSSNR3232(25*25 40*40) CCLNR2525(32*32 40*40)

BN-K1 solid cbn insert will be suitable for common lathe, CNC Lathe and others, it can be used for milling, turning and boring process. It will help manufacturers solve most problems on machining pumps.

6.FAQ

Q. How can we be your agent in our country?

A. Please inform us your detailed company, we will discuss and propose helpful suggestion for you, and to find the best solution for you.

Q. Do you offer free samples?

A. Normally we do not offer free samples, but we guaranty our product’s quality.

Q. Is there cheap shipping cost to import to our country?

A. For small order, Express will be the best, And for bulk order, sea ship way is best but take longer time. For urgent orders, we suggest via air to airport or by Express send to your door.

Q. When you can reply to me when I send you an Inquiry?

A. We promise to reply within 24 hours(not including holidays) on receipt of your inquiry.
