Cars plate reading automatically vehicle surveillance system scanning under
Cars plate reading automatically vehicle surveillance system scanning under
Specifications
Brand Name :
PEACENTURY
Model Number :
HPC-F
Place of Origin :
China(Mainland)
MOQ :
1
Price :
Negotion
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Cash
Supply Ability :
50/Week
Delivery Time :
5-7 working days
Packaging Details :
Wooden case Three parts 800*750*1460 cm*1 700*400*1210cm *1 670*380*1030 *1 G.W:295KG 1.23CBM
Name :
Under Vehicle Surveilance System
Useing :
Checking under vehicle
Scan resolution :
2048 line CCD
Chassis storage or loading time :
< 1 second
Display of scene image :
≥1 road
Resolution of the bottom image :
>12000 * 6144
The maximum of scan rate :
18kHz
Field of view :
170 degrees
Auxiliary lighting :
160W
Scanning device volume :
450 x 400 x 88mm
Monitor :
22 bits real colors
Waterproof degree :
IP68
Description

Cars plate reading automatically vehicle surveillance system scanning under

Access security control for vehicles at important location: Airports, government buildings, prisons, bank depot, military zones, seaports, police office, customs, border control, car park entrance checkpoint to important building's Toll station checkpoints, Checkpoints for entering and exiting vehicles attending conferences.

Features
FeaturesAutomatic digital line scan camera, with high-resolution and clarity of the image.
The complete image of under vehicle scanning, without any omissions, and the image is clear, complete, no distortion, can be clearly observed that the object is not less than 2mm in diameter.
Preparation of inspection processes to meet a variety of on-site needs.
Multiple scene image monitoring, recording function.
Multi-language user interface design.
Strong scalability to easily achieve a variety of system linkage control.
ALPR(Automatic Licence Plate Recognition) (Optional)
Multiple devices networked control functions(Optional)
General Specifications
Technical parametersVertical resolution of the image: 5000*2048 pixels
Check the width viewing angle: < 4 meters
Speed of vehicle:
< 30km/h with ALPR(Automatic Licence Plate Recognition)
70km/h without ALPR(Automatic Licence Plate Recognition)
Effective Field of View(FOV):less than 170°
Auxiliary light: 100W
Weight capacity: <20T
Water-proof grade: Ip68
Scanning device weight: 24KG
Scanning device volume: 450mm×400mm×88mm
Communication interface: RS232/RS422
Operating Temperature: -10ºC to 55ºC
Storage temperature: -40ºC to +75ºC
System host
System hostBrand: Grantech (UFO6377H-SP1-953)
CPU: Intel® Core(TM) 2 Duo CPU
P8600 2.4GHz or higher
Memory:2G( optional 4G)
Graphics:Inter(R) Gen 5.0 Integrated Graphics Engine
Hard Disk:SATA2 Hard Disk 500G
Dual LAN (At least one Intel Gigabit)
USB2.0 (Up to 4 pieces)
Monitor: 22inch LCD, resolution up to 1920*1080
Operating voltage: 110-240V AC, 50-60HZ


Specifications of under vehicle alarming system for car bomb checking:
Mobile Under Vehicle Imaging Component
1. Sensor: Line scan CCD
2. Resolution: 2048
3. Light Source: LED
4. Under Vehicle Image Data Transmission Interface: 100/1000M Ethernet
5. Dimensions: 550mm X 360mm X 85mm
6. Operating Temperature Range: -10 degree to +60 degree
7. Power Supply: 24VDC, 5A
8. Environmental Protection Level: IP68
Popular fixed under vehicle alarming system is also hot sale,
More detail, welcome send me inquiry.

For car bomb inspecting solution
Under vehicle inspection systemMobile model UV300M is easy for transfer to differet place
Under vehicle inspection systemFixed model UV300F with embedded camera can be used in raining day


Application:
1. Airport, prison, custom and other government department
2. Large public parking spot entrance and exit
3. Events, exhibition
4. Military, prison and other important checkpoints

Cars plate reading automatically vehicle surveillance system scanning under
