Specifications
Brand Name :
PRES
Model Number :
PEEK 1000
Certification :
ROHS REACH
Place of Origin :
China
MOQ :
100pcs
Price :
2-3
Payment Terms :
D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 piece per month
Packaging Details :
Inner In Poly Bags,wooden case
Thickness :
Custom,6-120mm
Material :
PEEK Resin
Color :
Natural,Black, customized
Density :
1.31
Product name :
High strength wear resistance natural color customized peek gear
Feature :
High wear resistance,abrasion resistance,Durable,260℃ working temperature
Application :
Automotive, mechanical manufacturing, aerospace, industrial automation, medical equipment
Sample :
To be negotiated,free sample
Shape :
customized gear
Packing :
Inner In Poly Bags,wooden case
Description

High strength wear resistance natural color customized peek gear

PEEK gear is a high-performance engineering plastic gear. Has excellent mechanical properties, high temperature resistance, corrosion resistance, and self-lubricating properties. PEEK gears have high strength, wear resistance, low noise, and can operate stably in harsh environments. Widely used in aerospace, automotive, mechanical manufacturing and other fields, it can replace metal gears, reduce weight and cost. Its excellent dimensional stability ensures precise transmission ratios and provides reliable solutions for various complex transmission systems, playing an increasingly important role in modern industry.

PEEK Parameters
NO. Item no. Unit PEEK-1000 PEEK-CA30 PEEK-GF30
1 Density g/cm3 1.31 1.41 1.51
2 Water absorption
(23℃ in air)		 % 0.2 0.14 0.14
3 Tensile strength MPa 110 130 90
4 Tensile strain at break % 20 5 5
5 Compressive stress(at 2% nominal strain) MPa 57 97 81
6 Charov impact strength(unnotched) KJ/m2 No break 35 35
7 Charov impact strength(notched) KJ/m2 3.5 4 4
8 Tensile modulus of elasticity MPa 4400 7700 6300
9 Ball indentation hardness N/mm2 230 325 270
10 Rockwell hardness -- M105 M102 M99
