Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling
Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling
Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling
Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling
Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling
Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling
Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling
Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling
Specifications
Brand Name :
PEERCHEER
Model Number :
BQ NQ HQ PQ
Place of Origin :
WuXi
MOQ :
2
Payment Terms :
T/T
Name :
BQ NQ HQ PQ COMPACT PLUS WATER SWIVEL
Model :
BQ NQ HQ PQ
industry :
Drilling
Price :
Negotiable
Certification :
ISO-9001
Packing :
export standard
Description

BQ NQ HQ PQ COMPACT PLUS WATER SWIVEL

PEERCHEER offers BQ NQ HQ PQ compact plus water swivel for use with BQ NQ HQ PQ core barrels and rods. BQ NQ HQ PQ compact plus water swivels are designed to provide a watertight or airtight rotating joint to connect the pump to the drill string with a high pressure hose. Most water swivels can use with a variety of flushing mediums including water, air, foam, or bentonite drilling fluids.compact plus water swivels are available to connect to standard BQ NQ HQ PQ coring system.

Compact Plus Bq Nq Hq Pq Drilling Water Swivel For Core Drilling

BQ NQ HQ PQ compact plus water swivel standard configuration:

1-Swivel Cap

2-Wavy Washer

3-O Ring

4-Water Swivel Packing

5-Wear Sleeve

6-Packing Cage

7-Thrust Bearing

8-Upper Swivel Body

9-Water Spindle

10-O Ring

11-Thrust Bearing

12-Water Swivel Body

13-Grease Fitting

14-Felt Seal

NOTE:

(1)16 NPT hose connection.

(2)W rod box spindle connection.

(3)5/8" spindle fluid porting.

BQ NQ HQ PQ Nonimal Weight(with adapter) kg Ibs
BQ Compact Plus Water Swivel(approx.) 10.00 22.05
NQ Compact Plus Water Swivel(approx.) 11.00 24.25
HQ Compact Plus Water Swivel(approx.) 12.00 26.46
PQ Compact Plus Water Swivel(approx.) 14.00 30.86

Our Services:

Ø Provide the technical design and solutions;

Ø Designing and manufacturing of non-standard equipment;

Ø Professional technical training and guidance on site according to the contract;

Ø Supply accessories at any time;

Ø Tele-technical consulting and services;

Ø Other special technical service according to client's requirements.

We specialized in producing of varies diamond drilling tools, such as impregnated/surface-set diamond core bits, diamond casing shoes, diamond rod shoes, reaming shells, TC core bits/casing shoes/TC rod shoes, PDC bits, Thin Wall Bits, core lifters, core lifter cases, core barrels, and kinds of drilling rigs etc.
