Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min
Specifications
Brand Name :
SANBI
Model Number :
RJHQ-800
Certification :
CE, ISO9001
Place of Origin :
ZHEJIANG,CHINA
MOQ :
one set
Price :
usd 25000 one set
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
30 sets one month
Delivery Time :
30 workdays
Packaging Details :
wooden package
Material :
Plastic film
Width :
250-600mm
Length :
250-730mm
Speed :
65-75pcs/min
Description

RJHQ-800 Fully Automatic Computer-Controlled Handle Bag Multi-functional Making-bag Machine

Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min

Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min

Automatic Bag Making Machine Polythene Bag Making Machine 65-75pcs/Min

Consulting Products

1. Characteristics:

This machine has four functions(soft loop handle bag, patch handle bag, poly draw handle bag, die cut handle bag) which is combined with machinery, optics, electric and pneumatic.

The whole machine adopts microcomputer control, Panasonic servo motor control system which can fix length of bag freely. Photoelectric tracker, accurate and stable, stopping automatically when the label is lost. Automatic pressure synchronous punching and synchronous sealing. Automatic counting which can set count alarm. Automatic constant temperature make the sealing firm and smooth.

a. Flexible soft loop handle and patch film feeding system, fully automatic.(patent)

b. Per-sealing knife, heated on double sides and strong for fusing, to make the bags without deformation.

c. The sealing knife is made of high queality material and without deformation even heated by high temperature.

d. Newly design of sealing knife top lift and turn over systerm

e. It’s designed by hesting punching, and it’s easy to cut off, the waster can fall off automatically.

2. Main Technical Parameter:

Model

RJHQ-800

Length of bag(mm)

250-730

Width of bag(mm)

250-600

Top-folding edge(mm)

50-75

Bottom inserting edge(mm)

20-70

Speed of bag-making

(pcs/min)

Soft loop handle bag

Patch handle bag

Poly draw handle bag

Die cut handle bag

60

60

70

70

Total power(kw)

13

Weight(kg)

3500

Overall Dimension(mm)

8200*3100*1870

3. Spare parts

01

thermocouple

3pcs

0

cutter blade

2boxes

06

solid-state voltage regulator

1pc

09

level earth foot plate

1set

10

silica gel oil (with one brush)

1 bottle

15

Switches, rotary knob: 2pcs each one

4pcs

16

Solid-state voltage regulator

2pcs

11

Rubber roll springs

20pcs

20

Power wire copper linker

5pc

21

Plastic belt

30pcs

03

small proximity switch(24V)

2pcs

14

small electric relay (four feet touching points, and two feet touching points: 2 pcs each one)

40pcs

13

Heating pipe: (side-sealing cutter: 1pc, soft handle:2pcs,pre-heating blade:2pcs, hot piercing: 2pcs, patch: 2pcs)

9pcs

02

high temperature stick tape (PTEE high temperature heating cloth: 2 meters)(made in Japan)

1roll

12

windpipe ￠4,￠6,￠8 windpipe linker: 2 pcs for each one

3meters

01

tool (tool box: 1 pc, inner hexagonal spanner: 1 set, screwdriver: 2 pcs, oil pot: 1pc, 8—10,12—14,17—19 open and wrench: 1pc each one)

1set

07

skew correction device operation instructions

1pc

18

inverter operation instructions book

1pc

19

Servo operation instructions book

1pc

17

Machine operation instructions book (with circuit diagram, gas circuit diagram)

pc
