Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC
Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC
Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC
Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC
Specifications
Brand Name :
Adcol
Model Number :
ATA100 - 12VDC
Certification :
ISO9001 , CE
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T , Paypal
Supply Ability :
500Pcs per month
Delivery Time :
3 - 4 Weeks
Packaging Details :
Solid Carton Packaging
Capacity-Qmax :
100W
Input Voltage :
12VDC
Running Current :
15.0amps
Start Current :
13.8amps
Hot Side Fans Current :
0.52amps
Cold Side Fans Current :
0.45amps
Description

Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC

ATA100-12VDC Thermoelectric air conditioners are designed for electronic cabinets, refrigeration and environmental chambers. They can cool to 72˚F below ambient or maintain ambient temperatures while removing up to 280 BTU/Hr (@ 77˚F ambient). Use 24VDC configuration, it could generate 80W power, if use 12VDC configuration, it could generate 100W power. These air conditioners are virtually maintenance-free, with no filters to change, and they can be mounted in any orientation, offering design flexibility with solid-state reliability.

Wiring Schematic (Power Connector)
Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC

Position Description
1 TEC +
2 TEC -
3 FAN +
4 FAN -


1 – Specification:

Model: ATA100-12VDC
Description Air to Air cooling System
Capacity- Qmax 100 Watts
Input Voltage 12 VDC
Working. Ambient Temp. 0~60˚C
TEM Current (Running) 15.0 amps
TEM Current (Start) 13.8amps
Hot Side Fans Current 0.52 amps
Cold Side Fans Current 0.45 amps
Weight Est. 2.8 kg
Rating Maintained NEMA 12
Overall Dimensions 203mm x 155mm x 213mm


2 - Installation Method and Cutout Dimension (in mm)

Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC

3 - Dimensional Drawing (in mm)

Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC

4 – Performance Curve

Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC
Semiconductors Thermoelectric Air Conditioner / Thermoelectric Air Cooler 100W 12VDC
