Specifications
Brand Name :
Adcol
Model Number :
ATL300-24
Certification :
ISO9001 , CE
Place of Origin :
China
MOQ :
1EA
Price :
Negotiation
Payment Terms :
T/T , Paypal
Supply Ability :
500pcs per month
Delivery Time :
3 - 4 weeks
Packaging Details :
Solid carton packaging
P/N :
ATL300-24-00-T10
Cooling Method :
Liquid Cool
Radiating method :
Air Force
Ambient temperature/humidity :
-20 to 60°C
Cooling Capacity :
300W+/-10%
Input Power :
360W
Outer dim for connector :
SMC L8/L10
Material of exchanger :
Al with hard oxidation
Hot/Cold side fan Current :
0.9A / NA
TEM Nominal/Startup Current :
14A/18A
Nominal/Max Voltage :
24/30 VDC
Overall dimension :
260mm x 158mm x 160mm
Noise :
52 dB
Weight :
5.5Kg
Life Time :
>=70,000 Hours
Tolerance :
10%
Description

ATL300-24-00-T10 Air To Liquid Thermoelectric Cooler Assembly 300W 24VDC Life Time70000Hours

ATL300-24-00-T10 Air to Liquid thermoelectric Cooler Assembly
The ATL300-24-T10 Thermoelectric air liquid is designed for cooling objects via liquid to transfer heat. Heat is absorbed through a liquid exchanger and dissipated by high density heatsink with fan.It could remove up to about 300W cooling, and is available in 24VDC configurations. Also it is virtually maintenance-free, and can be mounted in any orientation, offering design flexibility with solid-state reliabilit.
Features 特点
1.270W capacity rated at ΔT = 0ºC,Tambient = 30°C 在环境温度 30 度下制冷量约 300 瓦
2.Refrigerant free - environmentally friendly 不使用制冷剂-环境友好
3.Wide operating temperature range of –20°C to +60°C 使用环境温度宽–20°C to +60°C
4.Shift between heating and cooling without using a heater 加热制冷切换
5.Reduced noise and vibration with no moving parts 无机械压缩,运行安静可靠
Application 应用
1.Analytical instrument 分析仪器的冷却板
2.Medical diagnostics 医疗设备恒温
3.Industrial laser 工业激光水冷
4.Medical laser 医疗激光治疗设备水冷
ATL300-24-00-T10 Air To Liquid Thermoelectric Cooler Assembly 300W 24VDC Life Time70000Hours
ATL300-24-00-T10 Air To Liquid Thermoelectric Cooler Assembly 300W 24VDC Life Time70000Hours
ATL300-24-00-T10 Air To Liquid Thermoelectric Cooler Assembly 300W 24VDC Life Time70000Hours
