Specifications
Brand Name :
GreeF
Model Number :
GDF
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 Set
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
400 sets per month
Delivery Time :
20-25 working days
Packaging Details :
Foam + Plywooden Case
Rated Power :
0.5kW-5000kW
Rated Rotate Speed :
20rpm-3000rpm
Rated Voltage :
Customized
Magnet Type :
NdFeB
Generator Material :
Aluminium Body+Cooper Wire
Bearing :
SKF Bearing
Installation :
Horizontal / Vertical
Frequency :
50hz/60hz
Description
Product Description
Permanent Magnet Generators offer high efficiency energy conversion, particularly at partial load, and require no separate field excitation system. Our permanent magnet generators are lighter, more efficient, and require less assembly labor than competing designs.
Permanent Magnet Generators are used in a large number of applications such as Wind Turbines, Hydro Turbines, motors and others.
1
Rare earth Nd-Fe-B permanent magnets
2
Low Speed
3
Direct Drive ,no use gear-box
4
SKF bearing
5
Power factor close to 1
6
Maintenance free , can be used in all environments .
7
Long life time >20years, could run at high speed 24 hours 365 days .
8
Customized : Voltage, Speed, Power, Frequency etc.
9
Multi poles design, improve the frequency and efficiency of rectifiers and inverters.
10
H class insulation, vacuum pressure impregnation.
11
Excellent heat dissipation , also can add fan cooling
Advantages
Alternative Energy Generators
GREEF Company provide customized generator according to each customer 's requirements of Voltage, Speed, Power, Frequency etc.
Rated power
0.5--5000
kW
Rated rotate speed
20--3000
rpm
Rated voltage
48--1140
Vac
Frequency
60/50
Hz
Number of Poles
24
Generator type
3phase AC Synchronous generator
Magnet type
NdFeB
Winding Method
Y
Magnet temperature level
Max.120℃
Winding temperature level
Max.180℃
Effienciency
>95%
Insulate Grade
H
Insulating resistance
100Mohm Min(500Vdc)
Classification of degrees
IP54
Generatror shell material
Cast Iron
Winding material
100% Copper
Shaft material
Steel
Iron Core
Cold rolled silicon steel sheet
Bearing brand
SKF
Cooling Method
Fan Cooling
Weight (N.W /G.W )
132kg /152kg
Packing Size
870*470*570mm
Installation
Horizontal
Systems

Packaging & Shipping

1. Greef generator use inner foam protection, outer Plywooden case.

2. Package size and weight, please contact our sales.

3. Shipping by sea with FCL / LCL to your nearest port

Or Shipping by air to your nearest airport

Or Shipping by DHL/FedEx/UPS/TNT to your door

If you have any requests in package and shipping , please contact us directly.

10KW 20KW 50KW 1000KW Low Rpm Permanent Magnet Generator 1000RPM Free Energy10KW 20KW 50KW 1000KW Low Rpm Permanent Magnet Generator 1000RPM Free Energy

Our Services

All GREEF Generators are 3 years warranty for free, All lifelong technical support and part cost supply.

(1) The warranty period is start from the date of shipment which show on the bill of loading or air waybill.
(2) Free maintenance services during the warranty period the cost involved be borne by the company, do not charge a fee to customers, free warranty if any damage outside the warranty period, the company will charge a fee for labor costs and materials.
(3) the warranty period, company's quality problems caused by the maintenance of the freight borne by the company, if not under warranty or man-made damage, the freight charges by the customer.

Company Information

Qingdao Greef New Energy Equipment Co., Ltd are global supplier which focus on

Permanent Magnet generator, wind and solar hybrid generator systems solution,wind turbine

blades, controller, invertor etc.

GREEF have its own engineer design team which design products ourselves.

FAQ

1. Q: How your permanent magnet generator work?

A: Our generator need to be drive by other energy, like wind power, water power, belt, etc, then it can generating electric power.

2. Q: Can your magnetic generator produce electrical power by itself?

A: No, please refer A1.


3. Q: What is the power of your generator?
A: We can manufacture from 100w to 5000kw.


4. Q: What is the rotate speed of your generator?
A: From 20rpm to 3000rpm.


5. Q: Can you manufacture customized product?
A: Yes, we can.

Please tell your detailed request (power, rpm, voltage, size, color) to our sales, we will made the generator according to your request.


6. Q: Can your company provide OEM service?
A: Yes, we can.

If you have other requirements or questions, please feel free to contact us, we will reply you within 24 hours!
