Specifications
Brand Name :
GREEF
Model Number :
AH-5KW
Certification :
CE
Place of Origin :
CHINA
MOQ :
1Set
Price :
$299-12999
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
12
Delivery Time :
25 DAY
Packaging Details :
Foam+plywooden case
Blade material & Qty. :
FRP*3
Rated voltage(VDC) :
400/240/custom made
Rated power(kW) :
5
Rotor diameter(m) :
5.6
Gale protection :
Smart control+unattended
Description

5kw Variable Wind Turbine Generator Kit Vertical Axis Wind Turbine Blades

Technical specification
Model
AH-5KW
Rotor diameter(m)
5.6
Blade material & Qty.
FRP*3
Rated power(kW)
5
Rated wind speed(m/s)
11
Rated rotating speed(r/min)
240
Generator type
3-phase PMG
Working wind speed(m/s)
3-30
Start-up wind speed(m/s)
2.5
Survival wind speed(m/s)
60
Rated voltage(VDC)
400/240/custom made
Speed regulation method
Pitch-controlled
Wind answering method
Up wind
Stop method
Auto brake
Gale protection
Smart control+unattended
weight(kg)
400
Noise level(dB)
≤65
Tower height(m)
≥8
Tower model
Tilt-up tower
Working temperature
-20℃～+50℃
Products Description
Using the world's leading mechanical centrifugal variable pitch technology, the average annual power generation is 30% more.
(1) Large initial blade angle (+9 ), excellent acceleration performance, start at low wind speed of 2.5m/s;
(2) Below the rated wind speed, the wind turbine outputs efficiently;
(3) Above the rated wind speed, adjust the pitch angle so that the rotor speed is maintained near the rated speed and the power output is stable.
Project case

25kW Wind-solar-diesel Complementary Power Supply Project at Barracks of Garrison on Yongxing Island of Paracel Islands

New Energy Power Supply System at Communication Base Stations in Danish

On-grid Systems in Other Countries

The systems were also installed in countries, like India, the Phillipines, Ireland, Colombia,France, Brazil, Swiss and Hungary.
