Stainless Steel 304 Bottled Water Production Line

10000BPH / Water Filling Machinery

Description:

1. The CGF series bottled water filling line is used to fill mineral water or purified water into PET bottles from
2. 200ml to 2500ml.
3. Different models satisfy various requirements of output from 5000BPH to 30000BPH.
4. it'sa kind of production line for producing potable drinking water, purified water, mineral water.
5. the productionline mainly consists of water treatment equipment, blowing machine, filling machine, conveyor system,
6. packing machines. the whole process is automatic controlled by PLC.

Quick Detail:

Specifications:

1. Rated capacity: 10000 B/H for 500ml 5000B/H for 1L

2. Filling material: water

3. Bottle type: PET bottle；

Bottle diameter 55-110mm

Bottle height 186-310mm

4. Filling type: neck-hold conveyor

5. Cap: plastic screw cap

6. Filling temperature: normal temperature

7. Label: PVC sleeve label

8. Package: 4×6 film package ( 500ML)

9. Conveyor mode: empty bottle:Air conveyor

Full bottle:Conveyor belt

10. Condition: temperature:10～40℃

humidity:no dew(≤95％)

11. Resource power: 380V,50Hz,three phase

12. Efficiency: >95%

Applications:

1. Bottled mineral water production.

2. Bottled purified water production.

3. PET bottled water package.

4. PET bottle oil package is also avaliable.

The sample service:
1. we can send you the video of the running machine.

2. you are always welcome to come to visit our factory, and you may see the operation of the machines

here . We will make the arrangement to pick you up when you come .

3. If we get the permission of the customer who has brought the machines from us ,we can tell you their

contact information, you can go to visit their factory.

Customized service:
1. we can design the machines according your requirements(material ,power,filling type,the kinds of the

bottles, and so on).

2. at the same time we will give you our professional suggestion .

After-sales service:
1. we will provide the bill of load on time to make sure you can get the machine quickly

2. when you finish the Preparation conditions ,our engineer will go to your factory for the installation,

testing and also training .

3. we provide one year warranty with spare parts free.
