Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
Specifications
Brand Name :
StepChina/Mingstar
Model Number :
CGF24-24-6
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Supply Ability :
30 sets per year
Delivery Time :
30 days
Packaging Details :
wooden case
Capacity :
10000BPH for 500ml
Suitable bottle size :
200-2500ml
Bottle material :
PET Bottle
Operation :
Automatic
Material :
Stainless steel 304
Power :
380V 50HZ Three phase
Description

Stainless Steel 304 Bottled Water Production Line 10000BPH / Water Filling Machinery

Specifications:

1. Rated capacity: 10000 B/H for 500ml 5000B/H for 1L

2. Filling material: water

3. Bottle type: PET bottle；

Bottle diameter 55-110mm

Bottle height 186-310mm

4. Filling type: neck-hold conveyor

5. Cap: plastic screw cap

6. Filling temperature: normal temperature

7. Label: PVC sleeve label

8. Package: 4×6 film package ( 500ML)

9. Conveyor mode: Empty bottle: Air conveyor

Full bottle: Conveyor belt

10. Condition: temperature:10～40℃

humidity:no dew(≤95％)

11. Resource power: 380V,50Hz,three phase

12. Efficiency: >95%

Quick Detail:

Name

Water filling line, water production line, water bottling line

Brand Name

StepChina

Capacity

10000B/H for 500ml

Material

Stainless steel 304

Function

Water treatment, bottle washing, filling, capping, packing.

Usage

Bottled water production

Description:

1.Automatic bottling 3 in 1 filling machine adopt rinsing / filling / capping 3-in-1 technology, plc control, touch screen, it is mainly made of sus304 or sus316.

2.It is used for filling kinds of non-carbonated water, such as still water, drinking water.Mineral water, spring water, flavored water.

3.Its usual production capacity is in 2000-36, 000bph, 0.3-2l pet bottle is available.

4.Pivotal electrical part use mitsubishi, omron, siemens.

5.Filling accuracy is more or less than 1%.

6.We can provide bottle blowing machine, bottle filling machine, labeling machine, wrapping packing machine etc.Complete plant solution for pet bottle.With optional capacity from 2, 000-36, 000bph.

Mineral Drinking Water Filling Machine With Stainless Steel 304 Material

Applications:

1. Bottled mineral water production.

2. Bottled purified water production.

3. PET bottled water package.

4. PET bottle oil package is also avaliable.

Mineral Drinking Water Filling Machine With Stainless Steel 304 Material
