20L Orange Pet Bottle Blowing Machine With Automatic Thermostatic Apparatus
20L Orange Pet Bottle Blowing Machine With Automatic Thermostatic Apparatus
20L Orange Pet Bottle Blowing Machine With Automatic Thermostatic Apparatus
20L Orange Pet Bottle Blowing Machine With Automatic Thermostatic Apparatus
Specifications
Brand Name :
Eceng
Model Number :
YCQ-20L-1
Certification :
CE&SGS&ISO
Place of Origin :
China
MOQ :
1set
Price :
negotiate
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10sets per month
Delivery Time :
30 workingdays
Packaging Details :
Film pack
cavity :
single
Max volume :
20L
material :
pet preform
color :
orange
capacity :
400
power :
24W
Description

20L pet bottle preform blowing making machine

Model:YCQ-20L-1E

Technical parameter

item YCQ-20L-1E

Bottle type specification

 cavity 1
theory output (PCS/HR) 800-1000
Max. volume (L) 20L
Bottle mouth maximum overall diameter (mm) 150mm
Bottle biggest diameter 350mm
Bottle maximum height 550mm

Power specifications

 Light tube quantity 48pcs
Light tube power 1.5kw
Maximum heating power 72kw
All electric machine installation 75kw
Actual consumption 37.5kw

Air pressure specification

 Work pressure 7-9kg/cm2
Low-pressure gas consumption 1600Ltr/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 2000-3000 Ltr/min

Frozen water specification

 Work pressure 5-6 kg/cm2
Temperature range 10°C
Consumption 12000kcal/hr
Frozen water flow 88Ltr/min

Machine specification

 Size of the machine 5.2x2.0x2.0 (m)
Weight of the machine 6ton

Full automatic PET bottle blowing machine price / blow moulding machine

Product Description

Brief introduction of Full automatic 20L PET bottle blow molding machine

1. Stable performance with advanced PLC.

2. Conveying preforms automatically with conveyor.

3. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.

4. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.

5. High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.

6. No contamination and low noise with the air cylinder to drive the action instead of the oil pump.

7. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.

8. Two ways of operating: automatic and manual.

9. Safe, reliable, and unique design of the position of valve to make the air pressure diagram of the machine easier to understand.

10. Low cost, high efficiency, easy operation, easy maintenance, etc, with automatic technological process.

11. Contamination is avoided for the bottle body.

12. Ideal effect of the chilling with the chilling system.

13. Easy installation and starting

20L Orange Pet Bottle Blowing Machine With Automatic Thermostatic Apparatus20L Orange Pet Bottle Blowing Machine With Automatic Thermostatic Apparatus
