Smart High Speed Semi Auto Blowing Machine With Articulated Refueling Devices
Smart High Speed Semi Auto Blowing Machine With Articulated Refueling Devices
Specifications
Brand Name :
Eceng
Model Number :
YC-5L-2
Certification :
CE&ISO&SGS
Place of Origin :
China
MOQ :
1set
Price :
5000-10000USD per set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10sets per month
Delivery Time :
15working days
Packaging Details :
Film pack
Cavity :
2
capacity :
800BPH
Max volume :
5L
ecectric parts :
Omran
power cost :
24KW
Description

3L-5L plastic pure water bottle two cavity blowing machine

Features:

YC-5L-2Semi-automatic bottle blow molding machine can produce PET containers including the bottles for kinds of wine, drink, soybean,

vinegar, and pesticide (less than 5 liters) according to the different bottle shapes and diameters. It has automatic system with high

efficiency. The distant infrared ray heat pipe are used in the machine. It has high pressure protection with the feature of precisely

removing mould, The machine has low noise, It is easy to maintain, It’s the equipment for producing PET bottles.

Smart High Speed Semi Auto Blowing Machine With Articulated Refueling DevicesSmart High Speed Semi Auto Blowing Machine With Articulated Refueling Devices

Main machine Model type YC-2L-2 YC-5L-1 YC-5L-2 YC-20L-1

Product Spec

Max. product volume(L/cav)

 2L 5L 5L 20L

Max. preform neck size(mm)

 100 150 130 200

Max. product diameter(mm)

 180 200 200 400

Max. product height (mm)

 300 400 400 600

Cavities

 2 1 2 1

Blow molding part

Die force (KN)

 100 120 150 150

Die stroke (mm)

 270 320 300 340

Max. mould size(mm)

 390*345 390*350 390*530 420*500

Mould thickness

 Adjustable Adjustable Adjustable adjustable

Mould spacing(mm)

 Adjustable 400 400

Max. pulling stroke(mm)

 400 500 500 500

Operation pressure(Mpa)

 0.8-1.0 0.8-1.0 0.8-1.0 0.8-1.0

Operation air pressure consumption

(1tr/min)

 200 350 350 560

Blow pressure(Mpa)

 1.2-2.8 1.2-2.8 1.2-2.8 1.2-2.8

Blow air pressure consumption (1tr/min)

 300 300 360 650

Output(pcs/h)

 800 300 500-600 150

Machine size(LxWxH)(m)

 1.46*0.58*1.8 1.56*0.7*1.9 1.7*0.85*2.1 2.18*0.77*1.96

Machine weight(KG)

 650 700 800 1000

Oven

Temperature grade(rate)

 8 8 8 8

Heating time(S)

 90-200 90-200 90-200 90-200

Voltage(V)

 220 or as your request 220 or as your request 220 220
Frequency(HZ), 50/60 50/60 50/60 50/60

Total power(KW)

 16 16 16 15-40

Oven Size (LxWxH)

 1.35*0.55*1.15 1.45*0.65*1.15 1.45*0.65*1.15 2.37*0.68*1.65

Oven weight (KG)

 300 330 330 380

Smart High Speed Semi Auto Blowing Machine With Articulated Refueling Devices

Our Services

1. Reply the email and take action in 24 hours;

2. 100% Quality inspection before the shipment;

3. Can trainning clients operator for free in seller`s factory

4. Engineer overseas is avilable

5. Blowing mould and injection mould made orginal

6. Auxiliary machines for complate line.

7.Custimized design as requirements.
