High Speed Automatic Pet Blow Moulding Machine PLC Control With 4 Cavity
High Speed Automatic Pet Blow Moulding Machine PLC Control With 4 Cavity
High Speed Automatic Pet Blow Moulding Machine PLC Control With 4 Cavity
High Speed Automatic Pet Blow Moulding Machine PLC Control With 4 Cavity
Specifications
Brand Name :
Eceng
Model Number :
YCQ-2L-4
Certification :
CE&SGS&ISO
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10 sets per month
Delivery Time :
30 working days
Packaging Details :
FIlm pack
cavity :
4
PLC :
Mitsubishi
cylinder :
SMC
capacity :
4000
power :
36KW
color :
Orange
Description

high speed plastic pet container stretch blow moulding making

machine

What is technical parameter of our bottle blowing machine?

Bottle type specification

 cavity 4
theory output (PCS/HR) 4000-5000
Max. volume (L) 2L
Bottle mouth maximum overall diameter (mm) 28-38mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm

Power specifications

 Light tube quantity 32pcs
Light tube power 1.25kw
Maximum heating power 40kw
All electric machine installation 43kw
Actual consumption 21.5kw

Air pressure specification

 Work pressure 7-9kg/cm2
Low-pressure gas consumption 1600Ltr/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 3000 Ltr/min

Frozen water specification

 Work pressure 5-6 kg/cm2
Temperature range 10°C
Consumption 8000kcal/hr
Frozen water flow 88Ltr/min

Machine specification

 Size of the machine 4.5x1.6x1.9 (m)
Weight of the machine

3.5ton

A. Stable performance with advanced PLC.

B. Conveying preforms automatically with conveyor.

C. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.

D. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.

E. High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.High Speed Automatic Pet Blow Moulding Machine PLC Control With 4 Cavity

High Speed Automatic Pet Blow Moulding Machine PLC Control With 4 Cavity

How about our after-sale service ?

Provide whole drawing for the perform mould and bottle mould. Free charge for word design on the mould. We can help you

install the machine; from setting machine, testing, and to check the machine is on the good working condition. There is a litter

charge, only for flight charge and accommodation.

Warranty:

We response for one year warranty for the machine, however, it without any human conduct. And provide one-year free

spare part for client.

Up 15 million shots for the bottle mould.

3 million shots for the perform mould, cap mould.

All moulds are designed by CAD/CAM.

We also can provide the drawing for the mould, help you to maintain the mould, and machine.
