PLC Programmable Control 3 In 1 Filling Machine Plant Line For Ediable Oil Bottle
PLC Programmable Control 3 In 1 Filling Machine Plant Line For Ediable Oil Bottle
Specifications
Brand Name :
Eceng
Certification :
CE&ISO&SGS
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10 sets per month
Delivery Time :
30 working days
Packaging Details :
Film pack
warranty :
1 year
Weight :
3.3T
Bottle :
Plastic
Bottle Size :
0.1-2L
Capacity :
3000
Material :
SUS304
Description

PLC Programmable Control 3 In 1 Filling Machine Plant Line For Ediable Oil Bottle

Cooking oil ediable oil bottle filling machine plant line

This filling machine is a high-tech filling equipment controlled by microcomputer PLC programmable, equip with photo electricity transduction and pneumatic action.

Accurate measurement: adopt servo control system, ensure the piston can always reaches constant position.

When close to target filling capacity can be applied to realize speed slow filling, prevent the liquid spill bottle mouth cause pollution.

Convenient adjustment: replacement filling specifications only in touch screen can be changed in parameters, and all filling first change in position, fine-tuning dose it in touch screen adjustment.

Suitable material: Oil, jams, daily chemicals, and something that very viscous.

Main performance parameters:
1. Capacity: 50ml -100ml ≤ 6000b/h; 500ml ≤5000b/h; 1000ml≤4500b/h
2. Bottle Type: round bottle Φ40-100 mm, height 80-280 mm
Flat bottle (40-100mm)*(40-100mm)*(80-280mm)(L x W x H)
3. Diameter of bottle opening: ≥φ25mm
4. Filling range: 50-1000ml
5. Precision: (200ml) ±1%;(200ml-1000ml)±0.5%
6. Air pressure: 0.6~0.8 MPA
7. Power source: ~380V, 50HZ
8. Production line height: 900mm±50mm
9. Filling materials: cooking oil, jam, sauces and condiments, honey, etc
10. Bottle feeding direction: From left to right
