Automatic Pet Bottle Blowing Machine Drink Water Bottle Making Machine
Automatic Pet Bottle Blowing Machine Drink Water Bottle Making Machine
Specifications
Brand Name :
Eceng
Model Number :
q3000
Certification :
ce , iso
Place of Origin :
Zhangjiagang
MOQ :
1
Payment Terms :
L/C, T/T, MoneyGram
Delivery Time :
45 days
Packaging Details :
woden package
Application :
pet bottle making machine
Condition :
new
Blow moulding type :
stretch blow moulding
Automatic :
yes
Voltage :
380V/50HZ
Weight :
2.5tons
material :
pet preform
color :
orange
Description

Automatic Pet Bottle Blowing Machine Drink Water Bottle Making Machine

The pet bottle blowing machine is mainly used in PET performs blow bottles and other containers ,such as carbonated drinks bottle,pure water bottle,mineral water bottle ,cosmetic bottle,wide-mouth bottle, hot filling liquid bottle and other filling &packing containers.

Automatic Pet Bottle Blowing Machine Drink Water Bottle Making Machine

Model Q3000

Bottle type specification

 Cavity 2
Theory output 3000-4000
Max.volume 2L
Bottle mouth maximum overall diameter 28-38mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm
Power specification Light tube quantity 16pcs
Light tube power 1.5KW
Maximum heating power 24KW
All electric machine installation 27KW
Actual consumption 40%--70%

Air pressure specification

 Work pressure 7-9kg/cm2
Low-pressure gas consumption 1000L/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 3000Ltr/min

Air pressure specification

 Work pressure 5-6kg/cm2
Temperature range 10℃
Consumption 8000kcal/hr
Forzen water flow 88L/min

Machine specification

 Machine size 2.6x1.7x1.9
Machine weight 2.5ton

Automatic Pet Bottle Blowing Machine Drink Water Bottle Making MachineAutomatic Pet Bottle Blowing Machine Drink Water Bottle Making MachineAutomatic Pet Bottle Blowing Machine Drink Water Bottle Making MachineAutomatic Pet Bottle Blowing Machine Drink Water Bottle Making MachineAutomatic Pet Bottle Blowing Machine Drink Water Bottle Making Machine

Automatic Pet Bottle Blowing Machine Drink Water Bottle Making Machine
