500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance
500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance
500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance
500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance
500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance
500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance
Specifications
Brand Name :
Eceng
Model Number :
YCQ-2L-4
Certification :
CE&SGS&ISO
Place of Origin :
China
MOQ :
1
Price :
15000-20000USD per set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10sets per month
Delivery Time :
30days
Packaging Details :
film pack
color :
orange
capacity :
4000BPH
warranty :
2 years
weight :
3.5Ton
power :
36KW
Description

500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance

Feature:

A. Advanced PLC control system, stable and excellent performance.

B. Conveyor belt automatically feeds preforms.

C. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the

infrared pre-heater.

D. High adaptability,preform absorbs heat by adjusting the distance between lamp and reflector.With automatic constant temperature device,temperature is kept within a certain range.

E. Safety locks are provided during each mechanical action to protect operator's safety.

F. Use cylinder instead of hydraulic cylinder, low pollution, low noise.

G. Use different air pressure for blowing and machine operation,energy saving and environmental protection.

H. Equipped with high pressure and double-crank linkage clamping, providing high clamping force.

I. Two ways of operating: automatic and manual.

J. Safe, reliable, unique valve position design makes blowing process easier to control

K. Low-cost, high-efficiency, easy-to-operate, easy-to-maintain, advanced automatic process flow.

L. Avoid bottle contamination

M. Protection of low temperature cooling system

N. Easy to install and start

O. Low scrap rate

500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance

Item YCQ-2L-4
Bottle type specification Cavity 4
Theory output 3000-4500
Max. volume 2L
Bottle mouth maximum overall diameter 28-38mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm
Power specifications Light tube quantity 32pcs
Light tube power 1.25KW
Maximum heating power 40KW
All electric machine installation 43KW
Actual consumption 21.5KW
Air pressure specification Work pressure 7-9kg/ cm2
Low-pressure gas consumption 1600L/min
Blow bottle pressure 25-35kg/c㎡
Higher -pressure gas consumption 3000Ltr/min
Frozen water specification Work pressure 5-6 kg/c㎡
Temperature range 10℃
Consumption 8000kcal/hr
Frozen water flow 88L/min
Machine specification Size of the machine 4.5x1.6x1.9
Weight of the machine 3.5ton

500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance

500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance

500 Ml 5000BPH Soft Drink Carbonated Drink Pet Bottle Machine Excellent Performance
