Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type
Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type
Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type
Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type
Specifications
Brand Name :
Eceng
Model Number :
k6
Certification :
ce，iso
Place of Origin :
Zhangjiagang
MOQ :
1
Payment Terms :
L/C, T/T, MoneyGram
Delivery Time :
45 days
Packaging Details :
woden package
Application :
pet bottle making machine
Condition :
new
Blow moulding type :
stretch blow moulding
Automatic :
yes
Voltage :
380V/50HZ
Weight :
6.1tons
material :
pet preform
color :
black
Description

K series full-automatic pet stretch blow molding machine is the most stable two-step automatic stretch blow moulding machine. It has four to eight cavities and the maximum capacity of the products is 0.6L and 2.0L. It can blow bottles in shapes: Carbonated, mineral, pesticide, cosmetics, wide-mouth etc.

Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type

Model K6

Bottle type specification

 Cavity 6
Max.volume 2L
Bottle mouth maximum overall diameter 28-30mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm

Capacity specification

 Theory output 9000~12000BPH
Bottle type volume 500ML
Bottle type weight 17g
Bottle type Round
Power specification Light tube quantity 32pcs
Light tube power 1.25KW
Maximum heating power 40KW
All electric machine installation 49KW
Actual consumption 30%--60%

Air pressure specification

 Work pressure 5-6kg/cm2
Blow bottle pressure 25-45kg/cm2
Higher -pressure gas consumption 8000Ltr/min

Air pressure specification

 Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 8000kcal/hr
Forzen water flow 120L/min
Machine specification Machine size 5.5x1.8x1.9
Machine weight 6.1ton


Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type

Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type

Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type

Small Plastic Mineral Water Bottle Making Machine Automatic PET Blow Molding Type
