2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
Specifications
Brand Name :
ECENG
Model Number :
Q3000
Certification :
CE SGS ISO
Place of Origin :
CHINA
MOQ :
One
Payment Terms :
TT LC western Union
Supply Ability :
10sets Per month
Delivery Time :
45days
Packaging Details :
film/wooden
color :
Orange
output :
3000bph
Weight :
2.5ton
BLOW MOULDING TYPE :
Stretch Blow Moulding
VOLTAGE :
380V, 50HZ, 3PHASE
AUTOMATION :
automatic
VOLUME :
2l
Description

Eceng Q3000 2cavity Automatic Water Bottle Blowing Machine, 3000BPH, 2000ml Plastic Juice Bottles

model Q3000
Bottle type specification Cavity 2
Theory output 3000
Max.volume 2L
Bottle mouth maximum overall diameter 28-80mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm
Power specifications Light tube quantity 32pcs
Maximum heating power 24KW
All electric machine installation 27KW
Actual consumption 19KW
Air pressure specification Work pressure 7-9kg/cm2
Low-pressure gas consumption 1000L/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 1500Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10°C
Consumption 5000kcal/hr
Forzen water flow 30L/min
Machine specification Size of the machine 2.25x1.6x1.7
Weight of the machine 2.5ton

2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic

Q series fully automatic PET stretch blowing machine is developed by advanced bottle blowing technology.

1. Fully automatic operation: The Full Automatic Bet Bottle Blow Moulding Machine enables efficient and effortless production of high-quality bottles, as it is equipped with advanced automation technology.

2. High production capacity: With a production capacity of 3000 bottles per hour and 2cavity capability, this machine ensures that a large quantity of bottles can be produced in a short span of time, thereby enhancing productivity.

3. Perfect bottle shape and size: The Full Automatic Bet Bottle Blow Moulding Machine produces bottles of the desired shape and size with high precision, ensuring that your packaging needs are met to perfection.

4. Energy efficiency: This machine is designed to conserve energy, thereby helping you save on your energy bills and lowering your carbon footprint.

5. Low maintenance: With its durable design and advanced technology, this machine requires minimal maintenance, making it a cost-effective solution for your bottle production needs.

Company Introduction
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
Packing&Shipping
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
2cavity Automatic Water Bottle Blowing Machine Eceng Q3000 3000BPH 2000ml Plastic
