Specifications
Brand Name :
Eceng
Model Number :
H2
Certification :
CE ISO
Place of Origin :
Jiangsu, China
MOQ :
1set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 Set/Sets per Year
Delivery Time :
30days
Packaging Details :
To be packed in strong new wooden cases,suitable for long distance ocean for H2 pet water bottle blow molding machine
Plastic Processed :
PET
Warranty of core components :
1 Year
Condition :
New
Voltage :
380V/50HZ
Dimension(L*W*H) :
2.25mx1.6mx1.7m
Key Selling Points :
Easy to Operate
Applicable Industries :
Food & Beverage Factory
Theory output :
2200BPH
Description

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

If you're in the business of producing cosmetic bottles, you understand the importance of having an efficient, reliable machine to create your product. That's where the 2 Cavity 2200BPH Hand Feeding Pet Bottle Blowing Machine comes in. This machine is specifically designed to create cosmetic bottles at a high capacity and with precision accuracy.
With two cavities and a production rate of 2200BPH (bottles per hour), this machine is perfect for smaller businesses looking to scale up their production. It's also great for larger businesses looking for an additional machine to support their existing production line.

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Item H2
Bottle type specification Cavity 2
Theory output 2200
Max.volume 2L
Bottle mouth maximum overall DIdiameter 80mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm
Power specifications Light tube quantity 32pcs
Light tube power 0.75KW
Maximum heating power 24KW
All electric machine installation 26KW
Actual consumption 20KW
Air pressure specification Work pressure 7-9kg/cm2
Low-pressure gas consumption 1000L/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 1500Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 5000kcal/hr
Forzen water flow 30L/min
Machine specification Size of the machine 2.25x1.6x1.7
Weight of the machine 2.5ton
H linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. H series linear bottle blowing machine features:
1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.
4. manual and automatic methods of operation, human-machine interface control, simple operation.
5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.
6. less than 0.2% scrap rate for finished bottle .

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Our company, Zhangjiagang Eceng Machinery Co., Ltd. we are a special manufacturer of PET bottle blowing machine,blow molding machine and mould, We have been engaged in moulds for years, and have gained a well-known reputation from our customers who spread all over the world.

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 36,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging.
So far Eceng machinery have provided more than 2050 sets machines for more than 170 countries in the world.Our equipments are highly estimated by the clients, and are well known at home and abroad.We sincerely hope to establish business relationship with friends all over the world.
Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZEceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

our advantage:1. Resonable price;2. Good after service;3. experienced skilled workers and professional engineers;4. Good quality ,excellent service ,long life mould;5. on time delivery time;6.our engineers can be online for 24 hours to serve you.

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

Eceng Hand Feeding Pet Bottle Blowing Machine H2 2 Cavity 2200BPH 380V/50HZ

FAQ

Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
