Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Specifications
Brand Name :
ECENG
Model Number :
J series
Certification :
CE SGS ISO
Place of Origin :
CHINA
MOQ :
One
Payment Terms :
TT LC western Union
Supply Ability :
10sets Per month
Delivery Time :
45days
Packaging Details :
film/wooden
Weight :
2.5ton
Capacity :
High
Color :
Customized
Control System :
PLC
Material :
Plastic
Molding Method :
Blow Molding
Description
Candy Jar Blowing Machine 4Cavity 2400BPH For Food Jars Specification
Model
J4
Bottle type specification
Cavity
4
Theory output bph
2200-2400
Max.volum
2L
Bottle mouth maximum overall diameter
80mm
Bottle biggest diameter
100mm
Bottle maximum height
330mm
Power specification
Light tube quantity
32pcs
Light tube power
1KW
Maximum heating power
32KW
All electric machine installation
42KW
Actual consumption
30%--60%
Air pressure specification
Work pressure
7-9kg/cm2
Low-pressure gas consumption
1600L/min
Blow bottle pressure
25-35kg/cm2
Higher -pressure gas consumption
3000Ltr/min
Frozen water specification
Work pressure
7-9 kg/cm2
Temperature range
10℃
Consumption
8000kcal/hr
Forzen water flow
138L/min
Machine specification
Machine size
4.1x1.6x1.9
Machine weight
3.9ton

Candy Jar Blowing Machine: A Perfect Solution for Food Jar Production
When it comes to manufacturing high-quality food jars, it is essential to have the right machinery to ensure that the product is made to the highest possible standard. One such machine is the Candy Jar Blowing Machine 4Cavity 2400BPH, which is a state-of-the-art piece of equipment that can create high-performing food jars.

This advanced machine has a capacity of 2400 bottles per hour and produces four bottles simultaneously, making it highly efficient for companies that need to meet high demands. Moreover, the Candy Jar Blowing Machine 4Cavity has a wide range of applications, making it perfect for producing food jars such as candy jars, jam jars, honey jars, and many others.

Product Photo
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Working Process:
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Sketch Map:
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Exhibition
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
About Us
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Product packaging
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Packing
Conventional packaging: inside is wrapped with PE film outside is wooden box
Candy Jar Blowing Molding Machine 4Cavity 2400BPH For Food Jars
Delivery Conventional packaging: inside is wrapped with PE film outside is wooden box
After sale service
1.Installation, debug We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line.
2.Training Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.
3.the sample service ⅠWe can send you the video of the running machine. ⅡYou are welcome to come to visit our factory,and see the machine running.
4.We can design the machines according your requirements,at the same time we will give you our professional suggestion,as you know,we have been in this industry for 12 years.
5. Well-trained & experienced staff are to answer all your inquiries in English and Chinese
6. 12 Months guarantee and life-long technical support. 7. Your business relationship with us will be confidential to any third party. 8. Good after-sale service offered, please get back to us if you got any questions.
