Eceng Automatic 6000bph drink bottle making stretch blow moulding machine price
Features of cooking oil bottle blowing machine :
1. Stable and fine performance with advanced PLC.
2. Conveying perform automatically with conveyor.
3. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.
4. Well adjustability to enable the preheater to preheat preform in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.
5.High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.
6.No contamination and low noise with the air cylinder to drive the action instead of the oil pump.
7. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
8. Strong clamping force with high pressure and double crank links to lock the mold.
9. Low cost, high efficiency, easy operation, good interchangeability, easy maintenance, etc, with automatic technological process.
| Item | | Q6000 | |
| Bottle type specification | Cavity | 4 | |
| | Theory output | 6000 | |
| | Max.volume | 2L | |
| | Bottle mouth maximum overall diameter | 28-38mm | |
| | Bottle biggest diameter | 105mm | |
| | Bottle maximum height | 330mm | |
| Power specification | Light tube quantity | 32pcs | |
| | Light tube power | 1.5KW | |
| | Maximum heating power | 48KW | |
| | All electric machine installation | 52KW | |
| | Actual consumption | 40%-70% | |
| Air pressure specification | Work pressure | 7-9kg/cm2 | |
| | Low-pressure gas consumption | 1000L/min | |
| | Blow bottle pressure | 25-35kg/cm2 | |
| | Higher -pressure gas consumption | 3000Ltr/min | |
| Air pressure specification | Work pressure | 5-6 kg/cm2 | |
| | Temperature range | 10℃ | |
| | Consumption | 8000kcal/hr | |
| | Frozen water flow | 138L/min | |
| Machine specification | Machine size | 4.1x1.6x1.9 | |
| | Machine weight | 3.9ton | |
After sales service
* Instruction for Installation and Debugging
Before delivery, SMART takes responsible for debugging of cooking oil bottle blowing machine , in order to make sure the provided machine could be safely and smoothly put into operation.
SMART also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer of SMART, provides the engineer with round-trip tickets, accommodation, vehicle and salary.
* User Training
Technical training will be provided by SMART before delivery so that users would understand the machine features and how to operate the machine by themselves.
* Warranty Period
The warranty period for SMART machine is one year with a lifelong maintenance. If there is special requirement, other stipulated warranty period may be made after mutual agreement.
