3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
eceng
Model Number :
KB1
Certification :
CE/ISO
Packaging Details :
packed by wooden pallet or as customer request of 3 gallon 5 gallon water pet bottle blow molding machine
Supply Ability :
15 Set/Sets per Month
MOQ :
1set
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
60days
Plastic Processed :
PET
Condition :
New
Voltage :
220V or as customer request
Dimension(L*W*H) :
6.5*1.8*1.9
Hollow part volume :
20liter
Power (kW) :
49
Weight (KG) :
6000
Automation :
Automatic
Warranty :
1 Year
Key Selling Points :
Energy saving
Showroom Location :
Egypt, Turkey, United States, France, Viet Nam, Philippines, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kaza
Applicable Industries :
Food & Beverage Factory
Automatic :
Yes
Service :
Full technical training
Bottle volume :
MAX 20Liter
Weight :
6tons
Port :
Shanghai/Ningbo
Description

3L 5L 10L 15L 18L plastic containers bottles making machine 5 gallon blowing machine pri3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving




specification
Item
YCQ-20L-1
Bottle type specification
Cavity
1
Theory output
350
Max.volume
20L
Bottle mouth maximum overall diameter
150mm
Bottle biggest diameter
350mm
Bottle maximum height
550mm
Power specifications
Light tube quantity
48pcs
Light tube power
1.5KW
Maximum heating power
72KW
All electric machine installation
75KW
Actual consumption
52.5KW
Air pressure specification
Work pressure
7-9kg/c㎡
Low-pressure gas consumption
1600L/min
Blow bottle pressure
25-35kg/c㎡
Higher -pressure gas consumption
2000-3000Ltr/min
Forzen water specification
Work pressure
5-6 kg/c㎡
Temperature range
10℃
Consumption
12000kcal/hr
Forzen water flow
88L/min
Machine specification
Size of the machine
5.2x2.0x2.0
Weight of the machine
6ton
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
YCQ series is a stable two-step blow-down stretch automatic blowing machine. max volume 20L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.
Detailed Images
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
YCQ linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. YCQ series linear bottle blowing machine features: 1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. 2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs. 4. manual and automatic methods of operation, human-machine interface control, simple operation. 5. servo transmission system, high positioning accuracy, fast speed stability and good reliability. 6. less than 0.2% scrap rate for finished bottle .
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
our advantage
1. Resonable price
2. Good after service
3. experienced skilled workers and professional engineers
4. Good quality ,excellent service ,long life mould
5. on time delivery time
6.our engineers can be online for 24 hours to serve you
Company Introduction
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
Packing&Shipping
3L 5L 10L Stretch PET Bottle Blowing Machine 220V Energy Saving
After Sales Service
1.Installation, debug
We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line.
2. Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.
3.the sample service
1'We can send you the video of the running machine.
2'You are welcome to come to visit our factory,and see the machine running.
4.We can design the machines according your requirements,at the same time we will give you our professional suggestion,as you know,we have been in this industry for 12 years.
5.well-trained & experienced staff are to answer all your inquiries in English and Chinese
6 .12 Months guarantee and life-long technical support.
7.Your business relationship with us will be confidential to any third party.
8. Good after-sale service offered, please get back to us if you got any questions.
