High Efficiency Vacuum Belt Dryer With 1200mm×1500mm Shelf Dimensions
High Efficiency Vacuum Belt Dryer With 1200mm×1500mm Shelf Dimensions
Specifications
Brand Name :
LEADTOP
Model Number :
LTDG-20
Certification :
CE certification
Place of Origin :
China
MOQ :
1 set
Price :
discuss personally
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25 days/month
Delivery Time :
25days
Packaging Details :
wooden box
Model :
LTDG-20
Power :
65Kw, 380V±10%, 50HZ, 3Phase, 5Wire
Vacuum function :
9.6kw
Shelf spacing :
70mm
Shelf dimensions :
1200mm×1500mm
Usage :
fruit and vegetable
Description

LTDG-20 High efficiency freeze drying machine for Fruit Freeze Drying

Detailed Product Description:

Vacuum belt dryer is a continuous infeed and discharge vacuum drying equipment. Liquid product is conveyed into dryer body by infeed pump, evenly spread on belts by distribution device. Under high vacuum, the boiling point of the liquid is lowered; water in the liquid material is evaporated. Belts move on the heating plates evenly. Steam, hot water, hot oil can be used as heating media. With the moving of the belts, the product goes through from the beginning evaporating, drying, cooling to discharging in the end. The temperature decreases through this process, and can be adjusted for different products. Special vacuum crusher is equipped at the discharge end to produce different size end product. The dry powder or granule product can be automatically packed or continue with subsequent process.

Technical parameters:

Model LTDG-20
Total weight 9T(Approx.)
Power 65Kw, 380V±10%, 50HZ, 3Phase, 5Wire
Structure

Integral

Vacuum function

9.6kw
Shelf spacing 70mm

Shelf dimensions

1200mm×1500mm
Usage fruit and vegetable

High Efficiency Vacuum Belt Dryer With 1200mm×1500mm Shelf Dimensions
