High Performance Ultrasonic Cleaning Machine Vial And Ampoule Washing Machine
High Performance Ultrasonic Cleaning Machine Vial And Ampoule Washing Machine
Specifications
Brand Name :
LEADTOP
Model Number :
LTCX-5
Certification :
CE certification
Place of Origin :
China
MOQ :
1 set
Price :
discuss personally
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25 days/month
Delivery Time :
25days
Packaging Details :
wooden box
Model :
LTCX-5
Voltage :
380V 50 Hz
Power :
3KW
Water consumption :
10 multiple volume of bottle’s
Air Pressure :
0.35-0.45Mpa
Water pressure :
0.3-0.4Mpa
Description

High Performance Multi Functional Vial and Ampoule Washing Machine Model LTCX-5 Ultrasonic Cleaning Machine

LTCX-5 Ultrasonic Cleaning Machine

Summary:

This machine adopt PLC controlling, touch screen operating, freely adjusting the time of Ultrasonic washing. And can get rid of the surplus water in bottle. And adopt plate washing method to prevent bottle breaking. The ultrasonic washing machine meet the standards of GMP standard.

Working principle:

Push the plate which filled with ampoule bottles into washing, automatically filling water, when there is start signal press the PLC control button, when the plate descend into water, the cylinder will push plate into the ultrasonic energy exchangers, the washing time is about 25 minutes. After ultrasonic washing, the plates come into the rotation plate and then rotate 1800. To wash the outside of bottle by spraying and gas, then the bottles pushed by top cylinder come into the next inside washing process, the bottle plate break away the water, the mouth of bottle open adown. The washing head insert into the bottle, washing it by spraying water, gas, recycle three time.(Could be set in program).Then the gas washing will get rid of the surplus water inside the bottles. The finished bottles will automatically come out from outlet. Through the transition plates, the ampoule bottles will come into the tunnel sterilization and drying machine.

Technical parameters:

Model LTCX-5
Voltage 380V 50 Hz
Power 3KW

Water consumption

 10 multiple volume of bottle’s
Overall size 3260*700*1700mm
Air Pressure 0.35-0.45Mpa
Water pressure 0.3-0.4Mpa
Checking out rate of Cleaning

≥97%

High Performance Ultrasonic Cleaning Machine Vial And Ampoule Washing Machine
