NJP-800 Fully Automatic Capsule Filling Machines With High-Efficient

NJP-800 Automatic Capsule Filling Machine
NJP-800 automatic capsule filler processes the products for optimal productivity up to 800 capsules per minutes, featuring low-maintenance operation, minimal downtime, and overall dependable production. Powder dosing uses the 6 stage tamping technology for an enhanced accuracy. Filling of pellets is available.Capsules from the bunker are fed into the orienting device along the vertical guide.Then they are transferred into special cells on the rotor. Here the capsule is separated, after what the bottom part comes to the filling position.After filling the bottom part with the material, on next positions, the non-separated capsules are rejected, and the filled bottom parts are joined with top parts, counted and taken away into the receiving box.

Applications:
Our NJP Automatic capsule filler/filling machine adopts multi-bore dosing, intermittent motion and frequency control.
It suitable for automatically completing capsule feeding, separating, filling, (faulty capsule rejecting), closing, finished product ejecting for powder or micro pill medicine in capsule.
Its characteristics are advanced structure, the newest closed ten position rotating table, high precision low noise and best suitable for domestic machine-made capsule, and soon the key parts of the bearing and electrical equipment adopts international famous brand, performance stability and can be run at a high speed. All parts contacting the medicine powder are made of quality stainless steel, fine workmanship, provide dust collector device and made according to GMP standard.

Remarks
* cGMP design with emphasis in powder dust handling: Enclosed main turn table avoid dust getting into mechanical parts.
* Automatic control for capsule and powder supply.
* PLC control for reliable operation. Touch Screen HMI, featuring user-friendly controls:

production counter, manual/automatic /parameter setup modes, alarms.
* Precision capsule segments and dosing disk minimizes adjustments following parts changeover.
* SS 304 stainless steel frames and transparent safety interlock guards.

Main Technical Data:
