Medical Small Pill Single Rotary Tablet Compression Machine With Long Life
Medical Small Pill Single Rotary Tablet Compression Machine With Long Life
Medical Small Pill Single Rotary Tablet Compression Machine With Long Life
Medical Small Pill Single Rotary Tablet Compression Machine With Long Life
Specifications
Brand Name :
LEADTOP
Model Number :
GZP-57
Certification :
CE certification
Place of Origin :
China
MOQ :
1 set
Price :
discuss personally
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25 days/month
Delivery Time :
25days
Packaging Details :
wooden box
Model :
GZP-57
capacity :
40000tablets/hour
Max. Pressure(KN) :
60
Max. Tablet Thickness(mm) :
15
Max. Tablet Diameter(mm) :
20
name :
single rotary tablet compression machine
Description

Medical Small Pill Tablet Making Press Machine With Single Rotary

Product Description
This machine is a single-press type, continuous automatic tablet press for pressing the granular raw material into the round tablets and irregular tablets etc. It is especially caters for small-batch production.
This machine is mainly used in pharmaceutical industry and also the chemical, food, electronic, plastic and metallurgical industries.
In addition, it is equipped with the overload protection devices. The powder absorbing box is installed on one side of the machine. It can absorb the powder from the operation of the machine via suction port to avoid bonding and clogging, and it also can recycle the raw material for reproduction.

Features.

1. The outside part of the machine is full-enclosed. The material of the cover and internal table are made of stainless steel. The surface of turntable is specially disposed to keep the surface luster and prevent it from being polluted, meeting the GMP requirement.
2. It has transparent windows so that press condition can be observed clearly and windows can be opened for cleaning and maintenance. The lay-out of all the controllers and the operate parts is reasonable.
3. All the drive devices are located inside the machine so keep the machine clean.
4. The machine can press not only round tablets but also different geometrical shape tablets, double-layered and annular tablets, the tablets may have the impressed on both sides.
5. Overload protection unit is included in the system to avid the damage of the punches and apparatus, When overload occurs, the machine will stop working automatically.
6. Powder absorbing device could absorb the powder in the tablet-pressing room.

Application
It is mainly used for the production of tablets in the pharmaceutical industry, and is also suitable for the chemical, food, electronics and other industrial sectors.

Remark: There are automatical type and handwhell type for TEZP high speed tablet press machine

Main Technical Data:

Stations (unit) 17 Thickness of the die (mm) 28
Maximum compression (KN) 80 Diameter of the die (mm) 36
Max. Diameter of tablet to be produced (mm) 20 Rotary speed of the turret (rpm) 10-37
Max. Filling depth (mm) 22 Capacity of the tablets 37,700pcs/hour
Max. Thickness of tablet (mm) 6 Area to occupy (mm 2 ) 930x950
Diameter of the upper/lower shank (mm) 27mm Height of the machine (mm) 1750
Length of the upper punch (mm) 115 motor power (kw) 2
Length of the lower punch (mm) 183 Net weight of the machine (kg) 800

Machine Picture

Medical Small Pill Single Rotary Tablet Compression Machine With Long Life


Medical Small Pill Single Rotary Tablet Compression Machine With Long Life
