Factory Price Efficiency Ointment Packing Machine Encasing Machine for soap chemical cosmetics facial mask
This machine adopts imported PLC control each part of the photoelectric monitoring action, in the operation of the automatic picking waste unqualified items, such as abnormal, can automatically stop and display the reason, in order to troubleshoot in time, the machine can be used alone, or with the blister packaging machine, three dimensional packaging machine, vertical packaging machine, filling machine, labeling machine, printing machine, bag packing machine and so on machinery and equipment.Continuous use to form complete production line.
It's Suitable for the packing of soaps, daily chemicals, cosmetics, facial masks and similar articles. It can automatically complete the folding and folding of the instruction manual, the opening of the carton, the packing box of articles, the printing batch number and the sealing box at both ends of the carton.
Features:
1. International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.
2. Adopt human-machine operation system.
3. Automatically stop when machine is overload.
4. Automatically reject lacking of package product and leaflet.
5. Automatically display trouble, alarm and count finished products.
6. Stable performance,operation is easy.
Technical Parameters | |
Model | JDZ-120 |
Encasing speed | 30-120 boxes/min |
Carton quality requirement | 250-350g/m 2 (Based on carton size) |
Carton dimension range | L: 70-180mm, W: 35-85mm, H: 14-50mm |
Leaflet quality requirement | 60-70 g/m 2 |
Unfolded leaflet specification | (80-250)mm*(90-170)mm |
Fold range | 1-4 folds |
Working air pressure | 0.6MPa |
Air consumption | 120-160 L/min |
Voltage | 220V, 50Hz |
Power | 0.75KW |
Dimension | 3100*1100*1550mm(L*W*H) |
Weight | 1400KG |
