Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules
Specifications
Brand Name :
HUALIAN PHARMD
Model Number :
FD-VHJ
Certification :
ISO,GMP
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
80
Delivery Time :
50 DAYS
Packaging Details :
standard wooden case
Loading Capacity :
500
Voltage :
Customized
Power(W): :
4kw
Mixer Type :
Agitator
Product Type :
Detergent Powder
Material :
Stainless Steel
Name :
powder mixer
Description

V shape Series Mixer - Cosmetic Powder mixer

Introduction:
The V type cone mixer adopts manual feed and closed disc valve discharge, which can avoid dust spilling; with unique mixing barrel structure, high efficiency blending, and no dead angle,the materials can mix evenly. The inside and outside of machine are polished.It is suitable for smaller powder, blocks and the material that contain a certain mixture of water. In addition, the machine is also equipped with a timing device; In that case, you can control the material mixing time.

Application​:
The V type mixer blender is widely used for blending more than two materials(powder or granule shape)in pharmaceutical industry, chemical industry, foodstuff industry and so on.It is suitable for mix powder, granule material with good liquidity, small property difference. Because of the material in the v-shaped mixed container can flow smoothly, it will not destroy the base material, so the v-shaped mixer applies to easy to broken, easy wear granular materials,fine powder,and block materials with certain moisture content.

V cone mixer blender applied fields
The V type mixer blender is widely used for blending more than two materials(powder or granule shape)in pharmaceutical industry, chemical industry, foodstuff industry and so on.It is suitable for mix powder, granule material with good liquidity, small property difference. Because of the material in the v-shaped mixed container can flow smoothly, it will not destroy the base material, so the v-shaped mixer applies to easy to broken, easy wear granular materials,fine powder,and block materials with certain moisture content.

Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules

Technical characters:

The rotating cylinder of EYH Two Dimensionals Mixer can achieve two motions atthe same time. One is the rotation of the cylinder and the other is swinging of thecylinder along the swinging rack. The rotating cylinder of EYH Two Dimensionals Mixer can achieve two motions atthe same time. One is the rotation of the cylinder and the other is swinging of thecylinder along the swinging rack. As the result of these two motions,materials can be mixedfully in a short time. EYH Two Dimensions Mixer is suitable for mixing of allpowder and granule materials.

Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules

Laboratory Pharmaceutical Mixing Equipment / Cosmetic V Blender Machine FD-VHJ mixing dry powder or Dry granules

Main Technical Parameter:

Model VHJ-0.18 VHJ-0.3 VHJ-0.5 VHJ-1.0 VHJ-1.5 VHJ-2.0 VHJ-2.5 VHJ-3.0 VHJ-4.0 VHJ-5.0 VHJ-6.0
Productive capacity(kg/time) 72 120 200 400 600 80 1000 1200 1600 2000 2400
Model of vacuum pump W2 W2 W2 W3 W3 W3 W3 W4 W4 W4 W4
Time of raw material fed in(min) 3-5 3-5 4-6 6-9 6-10 8-13 8-15 8-12 10-15 15-20 18-25
Mixing time(min) 4-8 6-10 6-10 6-10 6-10 6-10 6-10 8-12 8-12 8-12 8-12
Total volume(m3) 0.18 0.3 0.5 1.0 1.5 2.0 2.5 3.0 4.0 5.0 6.0
Stirring speed(r/min) 12 12 12 12 12 12 12 10 10 10 10
Motor power(kw) 1.1 1.1 2.2 4 4 5 7.5 7.5 11 15 18.5
Rotation height(mm) 1580 1760 2400 2840 3010 3240 3680 3700 4350 4800 5300
Weight (kg) 280 320 550 950 1020 1600 2040 2300 2800 3250 3850
Main Features:
1. Compact structure, operation simple and maintenance convenience.
2. Using stainless steel material, prevent the mixing materials from being polluted .
3. The machine adopts V type asymmetric mixing vat to compound , no dead angle, no accumulation of materials, high speed, short mixing time and high uniform mixing.
4. Running steady and lower noise
5. Equipped with a timing device, it can set mixing time to realize automatic stop .


​

​
