GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
Specifications
Brand Name :
HUALIAN PHARMD
Model Number :
FD-SZG
Certification :
ISO,GMP
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10 Set/Sets per Mont
Delivery Time :
50 DAYS
Packaging Details :
standard wooden case
Model No :
FD-SZG
Speed(rpm) :
6
Power(Kw) :
1.1
Tolal weight(Kg) :
550
Product Name :
Pharmaceutical Granulation Equipments
Brand :
HUALIAN PHARMD
Description

Factory price double cone rotary vacuum dryer for drying food powder and medicine​

Description:

SZG Series Conical Vacuum Dryer is a new generation drying device developed byour factory on the basis of combining the technology of similar equipment. It hastwo connecting ways, i.e. belt or chain. Therefore it is stable in operation. Thespecial design guarantees two shafts realize good concentricity.
Heat medium andvacuum system all adapt reliable rotating connector with the technology fromUSA. On this basis, we also developed SZG-A. It can carry out steppless speedchange and constant temperature control.
As a professional factory in drying industry, we supply hundred sets to thecustomers every year. As for heat medium, it may be thermal oil or steam or hotwater. For drying the adhesive raw material, we have designed specially a stirringplate buffer for you.

GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine

GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine

Principle:

● Heat source (for example, low pressure steam or thermal conduct oil) passthrough the sealed jacket. The heat will be transmitted to raw material to bedried through inner shell;
● Under driving of power, the tank is rotated slowly and the raw material inside itis mixed continuously. The purpose of reinforced drying can be realized;
● The raw material exists is under vacuum. The drop of steam pressure makesthe moisture (solvent) at the surface of raw material become saturation and willevaporate. The solvent will be discharged through vacuum pump an recoveredin time. The inner moisture (solvent) of raw material will infiltrate, evaporate anddischarge continuously. The three processes are carried out unceasingly andthe purpose of drying can be realized within a short time.

GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine

GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine

Technical characters:

1. When oil is used to heat, use automatic constant temperature control. It can beused for drying biology products and mine. Its temperature of operation can beadjusted form 20-160 "C .
2. Compared to ordinal dryer, its heat efficiency will be 2 times higher,The heat is indirect. So the raw material can not be polluted. It is in conformitywith the requirement of GMP.
3. It is easy in washing and maintenance.

GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine

GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine

Main Technical Parameter:

Itme
Name Unit 100 200 350 500 750 1000 1500 2000 3000 4000 5000
Total volume L 100 200 350 500 750 1000 1500 2000 3000 4000 5000
Working volume L 50 100 175 250 375 500 750 1000 1500 2000 2500
Heating area ㎡ 1.16 1.5 2 2.63 3.5 4.61 5.58 7.5 10.2 12.1 14.1
Speed rpm 6 5 4 4 4
Power Kw 0.75 1.1 1.1 1.5 2.2 3 4 5.5 7.5 11 15
Rotating height mm 1810 1910 2090 2195 2500 2665 2915 3055 3530 3800 4180
Total weight Kg 550 700 900 1100 1200 1300 1500 2000 3000 4000 5000
Design pressure inside the tank Mpa -0.09~0.096
Design pressure of jacket Mpa ≤0.3

Schematic of installation:​

GMP Double Cone Rotary Vacuum Dryer For Drying Food Powder And Medicine
