Stainless Steel Pharmaceutical Automatic Powder Capsule Filling Machine
Stainless Steel Pharmaceutical Automatic Powder Capsule Filling Machine
Stainless Steel Pharmaceutical Automatic Powder Capsule Filling Machine
Stainless Steel Pharmaceutical Automatic Powder Capsule Filling Machine
Specifications
Brand Name :
SED Pharma
Model Number :
SED-2500J-H
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T,L/C, MoneyGram,Cash
Supply Ability :
30 Sets Per Month
Delivery Time :
40 Working days after receiving advanced payment or original L/C
Packaging Details :
Wooden Case
Name :
Stainless Steel Pharmaceutical Automatic Powder Capsule Filling Machine
Suitable Capsule Size :
00#-4# capsule
Power Consumption :
6.79kw
Noise :
≤75dB(A)
Dimension :
1200mm (L) x 1050mm(W) x 2100mm(H)
After-sales service provided :
Engineers available to service machinery overseas,No overseas service provided,Free spare parts
Type :
Filling Machine
key word :
Capsule Filling Machine Automatic Capsule Filling Machine
Description

Stainless Steel Pharmaceutical Automatic Powder Capsule Filling Machine

Product Parameters of Oil Capsule Filling Machine​
SED-2500J-H Automatic Capsule Filling Machine is commonly used in the pharmaceutical, nutraceutical industries to fill empty hard gelatin capsule of various sizes with powders and pellets (optional). The capsule filler automatically orientates, opens the empty hard gelatin capsule, properly fills the capsule with powder, and automatically closes the capsules.

Model SED-2500J-H
Capacity 2500 capsules/min
Filling Material Powder, Granules
Die Hole Number 18
Power Supply 380V 50Hz 3P
Total Power 6.97KW
Application 00#-4# capsule
Filling Variation ±3% - ±4%
Noise ≤75dB(A)
Qualified Rate ≥99.5%
Overall Dimension 1200mm (L) x 1050mm(W) x 2100mm(H)
Weight 1300kg

Feature of Oil Capsule Filling Machine​

1.The internal design of the mold turntable is improved, and the original Japanese linear bearing is used to ensure the accuracy and service life of the equipment.
2.The design of underslung cam and pressure atomizing oil pump reduces wear and prolong the service life of parts.
3.Adopt PLC control, stepless frequency conversion speed regulation, and touch screen display, ensuring convenient and intuitive operation.
4.Based on the lower plane of the dosage plate, three-dimensional adjustment and uniform gap, the filling accuracy can be effectively ensured, and it is very convenient for cleaning.
5.Equipped with a safety protection device for man and machine, and an automatic stop device for lack of material, so that the machine runs smoothly, safely and reliably.

Application of Oil Capsule Filling Machine

Fill oil liquid product, solution, suspension liquid or paste into hard gelatin capsule. Suitable capsule: 00#, 0#, 1#, 2#, 3#, 4#

Stainless Steel Pharmaceutical Automatic Powder Capsule Filling Machine
