High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
Specifications
Brand Name :
SED Pharma
Model Number :
SED-7500J-C
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T,L/C, MoneyGram,Cash
Supply Ability :
30 Sets Per Month
Delivery Time :
40 Working days after receiving advanced payment or original L/C
Packaging Details :
Wooden Case
Name :
High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
Material :
Stainless Steel
Capacity :
7500 capsules per minute
Power :
13.5kw
Filling Rate :
≥99.5％
Weight :
3800kgs
Dimension :
1700×1220×2150mm
Power Supply :
380V 50HZ Three Phase
Description

High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine

Product Description of Capsule Filling Machine

Fully automatic capsule filling machine is a professional capsule filling equipment, mainly used in pharmaceuticals, health products, hospital preparation rooms and other industries. It adopts hole-type filling, intermittent operation, etc., which can

automatically complete the filling and dividing of capsules. , filling, (waste capsule removal) locking capsules, finished product output and other processes are not only safe, hygienic, and reliable, but also have high precision, strong sealing, low noise, and

high output, meeting the needs of modern production.

Detailed Parameters of Capsule Filling Machine​

Model SED-7500J
Data Weight 3800kg
Dimension 1700×1220×2150mm
Motor power 13.5kw
Power Three phase four wire AC 380V;50Hz
Capacity 408000pcs/hour
Filled capsule sizes 00#～5#,A～E
Fiiling rate ≥99.5％
Noise ≤75dBA
Filling Difference

300mg≤±3％
(40~80 mesh granules after granulation)
Compressed Air 0.09m3/min 0.3Mpa
Vacuum rate -0.02～-0.06 MPa
Working temperature 21℃±3℃
Workshop Height Manual Loading≥2.6m,Vacuum Loading≥2.8m
Working Humidity 40～55％
Air exhaust capacity 300m3/h
Control mode Inverter,PLC


Characteristic of Capsule Filling Machine
1. Working steady, safe and reliable enough.


2. Capsule qualified rate is more than 99% with the precise dosage.


3. Timing frequency-conversion, programmable controlled.


4. New closed structure, accord with GMP standard.

Main Features

1. Hard Gelatin automatic capsule filling machine has been improved the inner design turret, and imports beeling bearing for each machine from japan directly, so that it can be sure a longer usage life and precision of the machine.

2. The working station cam runs under the good lubricating condition, and maintains the inner lunbrication of cam slot to a full extent, increasing the pressure pulverization oil pump, thus extends the operation life of the spare parts.

3. The automatic capsule filling machine is controlled by PLC, has as stepless timing with the frequency conversion the numeral showing makes an easy operation and clear appearance.

5. The multi-bore dosing bring a precision dosage; the good capsule applicability makes a high capsules qualified rate more than 99%. It can be filled with the Chinese traditional medicine and the western medicine.

6. Add the extra function of capsule control switch. Control the capsule outside of the machine, it is more safely and quickly.

7. Add the click-moving control system, make and easier operation and clearness.


High Speed PLC Controlled Automatic Capsule Filler Capsule Filling MachineHigh Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine

Application of Capsule Filling Machine

High Speed PLC Controlled Automatic Capsule Filler Capsule Filling Machine
