High Precision Pharma Machinery Tablet Pill Press Machine
High Precision Pharma Machinery Tablet Pill Press Machine
Specifications
Brand Name :
SED Pharma
Model Number :
SED-420-31Y-B
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T,L/C, MoneyGram,Cash
Supply Ability :
30 Sets per month
Delivery Time :
35 Days after receiving the deposit
Packaging Details :
Wooden Case
Name :
High Precision Pharma Machinery Tablet Pill Press Machine
Model :
SED-420-31Y-B
Stations (unit) :
31
Max. Diameter of Tablet :
22
Maximum compression (KN) :
80
Max. Thickness of Tablet :
6
material :
stainless steel
key word :
Tablet Press Machine
Description

High Precision Pharma Machinery Tablet Pill Press Machine

Product Description of Tablet Press Machine

SED-420-31Y-B Automatic Rotary Tablet Press is a double-press multifunctional automatic rotary continuous tablet press machine, which presses granular raw materials into tablets. It is mainly used in the production of the pharmaceutical industry, and is also used in chemical, food, electronics and other industrial sectors. It can press special-shaped tablets, double-layer tablets, circular tablets, etc. according to customer requirements.

Features

  • The outer casing is fully enclosed, and the material is made of stainless steel. The inner table is also made of stainless steel, which can maintain the surface gloss and prevent cross-contamination, in line with GMP requirements.
  • Equipped with plexiglass perspective window which could help to observe the status of tablet pressing. The transparent protective cover could be fully opened, easy to clean and maintain.
  • All monitors and operating components are in good order.
  • Applying with frequency changing, speed regulating apparatus to do electricity regulation. The convenient operation and smooth revolving are safe and correct.
  • Equipped with over-load protection apparatus. When pressure overloads, the machine will stop automatically.
  • Equipped with touch screen, easy to operate.
  • Transmitting system is sealed in the oil box under the main machine which is a separate component .No pollution and easy to send out heat and resist grinding.
  • Powder-absorbing apparatus could absorb the powder in the piece-pressing room.

Product Parameters of Tablet Press Machine

Number of Punch Die 31
Capacity 135000 pcs/h
Max. Working Pressure 80KN
Max. Diameter of Tablet 22mm
Max. Thickness of Tablet 6mm
Max. Filling Depth 15mm
Turret Speed 14-36rpm
Motor Power 3-5.5KW
Net Weight 1700kg
Overall Dimension 1230*950*1670mm

Application of Tablet Press Machine

High Precision Pharma Machinery Tablet Pill Press Machine
