Four Head Plastic Ampoule Oral Liquid Filling Machine
Four Head Plastic Ampoule Oral Liquid Filling Machine
Specifications
Brand Name :
SED Pharma
Model Number :
SED-4GX
Certification :
CE
Place of Origin :
China
Name :
Four Head Plastic Ampoule Oral Liquid Filling Machine
Number of :
50-80 bottles / min
Applicable Objects :
Oral liquid bottle, ampoule bottle, etc. (can be customized according to the bottle)
Specification :
5-30ml（can be customized according to the bottle)
Voltage :
380V/220V
Filling Accuracy :
<0.5%
Bottling Coverage :
>99%
Size :
2160*1200*1500(mm)
Description

Four Head Plastic Ampoule Oral Liquid Filling Machine

Product Description

Name
Four Head Plastic Ampoule Oral Liquid Filling Machine
Model
SED-4GX
Applicable Objects
Oral liquid bottle, ampoule bottle, etc. (can be customized according to the bottle)
Specification
5-30ml(can be customized according to the bottle)
Production Capacity
50-80 bottles/min
Voltage
380V/220V
Filling Accuracy
<0.5%
Weight (kg)
350 kg
Overall dimensions (length x width x height)
2160*1200*1500(mm)

1. PLC control, stepless speed regulation.
2. The 7 positions of paper, plastic molding, filling, batch number, tail trimming, and cutting are all executed automatically by the program.
3. The man-machine interface device, the operation is simple and clear.
4. The filling head does not drip, bubble, or overflow.
5. The relevant parts in contact with the liquid are made of high-quality stainless steel materials, which conform to the GMP standard.
6. Main pneumatic components and imported electrical accessories.
7. The electronic peristaltic pump controls the filling system and the mechanical filling, and the accurate measurement error is small.

Application:

Oral liquid bottle, ampoule bottle, etc. (can be customized according to the bottle),5-30ml(can be customized according to the bottle).
Four Head Plastic Ampoule Oral Liquid Filling MachineFour Head Plastic Ampoule Oral Liquid Filling Machine
