DPB-80 Automatic Blister Packing Machine
DPB-80 Automatic Blister Packing Machine
Specifications
Place of Origin :
China
Brand Name :
Royal
Certification :
CE
Model Number :
DPB-80
MOQ :
1 Set
Packaging Details :
Export standard wooden carton package
Delivery Time :
25 days after receiving the deposit
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
10 Set/Sets per Month
Price :
USD6500~9500
Description

DPB-80 Flat Plate Automatic Blister Packing Machine

Product Name

Flat Plate Automatic Blister Packing Machine

Product model

DPB-80

Product specify

It is suitable for capsule, tablet, big honey pill, candy, liquid, paste, one injector as well as irregular shape Al-plastic, paper-plastic composite sealing packaging in pharmacy, healthcare, food, cosmetics, medical equipment industry etc.

Instruction and features:

The machine is of flat-plate structure, with pressing, molding, meshes heat-sealing, adjustable travel range, for small size of body and ease of operation. It is applied to Al-plastic packaging for capsule, tablet, candy, healthcare, small hardware etc.

It is widely used in small pharmacy factory, preparation-room of hospital institute laboratory; mini motor test workshop .The machine reaches advanced level in china.

With manipulator towing and adjustable travel range, it can be suited for blister packing of various sizes.

Flat plate structure can pack special shape products, such as: elliptic shape, square shape, triangle shape liquid, paste and syringe etc

The whole procedure of feeding, forming, heat-sealing, impressing, batch number printing and cutting is accomplished automatically and continuously machine is small in size , with frequency inverter and ease of operation.

Notes:

·Eye marking sealing device with sensor trace can be added for option

·Plexiglas cover can be added for option.

Main technical parameters:

Cutting Frequency(stroke/min)

10-40

Max. Production Capacity(blister/min)

40(According to standard plate 80*57)

Max. Forming Area and Depth(mm)

80*100*26 (Standard 70*90*14)

Travel Range(mm)

20-80(Can be manufactured as use's requirements)

Air Pressure(Mpa)

0.4-0.6

Standard Plate(mm)

80*57(Can be manufactured as user's requirements)

Total Power

380V/220V 3.6kw

Main Motor Power (kw)

0.75

PVC Rigid Sheet(mm)

0.15-0.5*100

PTP Aluminum Foil(mm)

0.02-0.035*100

Dialysis Paper(mm)

50-100g*100

Mould Cooling

Tap Water Or Circulating Water

Overall Dimensions(mm)

1400*460*950(L*W*H)

Weight(kg)

450
