Specifications
Brand Name :
BonTek
Model Number :
Lithium Niobate (LiNbO3)
Certification :
ISO:9001, ISO:14001
Place of Origin :
China
MOQ :
5 Pieces
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
10000 pieces/Month
Delivery Time :
1-4 weeks
Packaging Details :
Cassette / Jar, put in a carton with PE foam.
Material :
Lithium Niobate Wafer
Size :
3inch, 4inch, 6inch, 8inch
Cut Angle :
X, Y, Z, 64Y, 128Y, 41Y
Thickness :
0.20mm - 3mm
Surface :
Double side polish, Single side polish, Lap
Application :
Surface Acoustic Wave, Bulk Acoustic Wave, Semiconductor, Optical
Roughness Ra :
<0.5nm
Dope :
Er, MgO, Fe, Er:MgO
Description

3 Inch Lithium Niobate (LiNbO3) Wafer 64Y 128Y Single Side Polished For SAW

Lithium niobate has good nonlinear optical properties, so it can be used as optical waveguide material, as well as to make low and medium frequency surface acoustic wave filters and high power high temperature resistant ultrasonic transducers. Lithium niobate doping is widely used at present, such as Mg:LN, Nd:Mg:LN, Fe:LN and so on.

Lithium tantalate has good piezoelectric, ferroelectric, acoustooptic and electro-optic effects. Widely used in resonators, filters, transducers and high-frequency surface acoustic wave devices.

Material

3" 4" 6" 8" LN wafer Saw/Optical grade

Orientation

X / Z / Y41° / Y64° / Y128° / YZ / YX or Customized

Surface finish

single or double sides polish (DLP/SLP/ SSP/DSP all available )

Thickness

0.18/0.25/0.35/0.50/1.00 + mm

TTV

< 1~5µm

BOW

± (20µm ~40um )

Warp

<= 35µm

Orientation flats

available, per request

Polished side Ra

Roughness Ra<=5A

Back Side Criteria

Roughness Ra:0.5-1.0µm GC#1000

Edge Rounding

Compliant with SEMI M1.2 Standard/refer to IEC62276

3 Inch Lithium Niobate Wafer 64Y 128Y Single Side Polished For SAW3 Inch Lithium Niobate Wafer 64Y 128Y Single Side Polished For SAW

3 Inch Lithium Niobate Wafer 64Y 128Y Single Side Polished For SAW

FAQs:

  1. Q: What are the products you mainly work on?

A: We look at ourselves as the piezo wafer specialist. We are the very first to work with Single Crystal Quartz in China about 30 years ago. Then gradually we step in the field of LiNbO3, LiTaO3, Quartz glass, LGS, CTGS etc. Especially, if you are looking for a piezo quartz supplier, we are the ultimate choice! We export millions of quartz blanks each year because we master the AT, SC and IT cuts with superior angle precision.

  1. Q: Can you accept product customization?

A: Yes, of course. We can fabricate as per your request. In addition, we are so experienced with piezo wafers that we can provide you relevant suggestions if you are not 100% sure about your choice. Besides, we do have some standard wafers in stock, please check with us.

  1. Q: Can you deliver the goods via our courier agent?

A: Yes, we would suggest you go with the courier agent you are most familiar with (DHL, FedEX, UPS etc.). We can ship via your account. And, of course, we will pack the products safely in acceptable size to help you save the shipping cost. If you need us to take care of the freight, it’s also not a problem. We also have good discount with the international courier companies.

  1. Q: How can you guarantee we get what we want safely?

A: The wafer products are fragile and sometimes expensive. The last thing, as the manufacturer, we want to see is the products we make were damaged during courier. As a result, we will pack the wafers adequately and put them in a proper carton filled with buffer sponge. However, accidents are inevitable sometimes. So, please follow the “Acceptance check” steps shown in the drawings below. If the unwanted happened, we will either give the replenishment or refund if you follow the checking steps.

  1. Q: Can we visit your factory?

A: Sure. Factory inspection is important for large quantity purchase and long-term cooperation. Face to face discussion is what we mostly confident with. During the past years, big names around the world have witnessed our progress in factory build-up. These days, due to the Covid-19 pandemic, we also had the experience of videoconferencing with global buyers.

Acceptance Check

3 Inch Lithium Niobate Wafer 64Y 128Y Single Side Polished For SAW

1. The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.

2. After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.

3. Please open the vacuum package in a clean room when the products are to be applied.

4. If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
