Specifications
Brand Name :
Tianfeng
Model Number :
ZPW21 ZPW23
Certification :
CE/ISO
Place of Origin :
Shanghai, China
MOQ :
1 unit
Price :
welcome to consult
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 units/month
Delivery Time :
45 working days
Packaging Details :
export wooden case
Voltage :
220V/380V, 50HZ/60HZ
Condition :
New
Warranty :
13 months
After-sales service provided :
Engineers available to service machinery overseas
Power(w) :
7.5 KW
Power source :
Mechanical, electric
Type :
rotary type, Tablet Pressing Machine, granules powder Tablet Press Machine
Usage :
3 layer tablets, effervescent pills making
Description

Applications:
This machine is used to make different kinds of granular materials compressed into flake, the advantage is not only can suppress the shaped pieces of various geometric shapes, double-layer tablets, ring-chip and double lettering pieces but also can suppress the round-chip piece.
During operation, the depth of filling material and the thickness of the tablets can be adjusted.
When overload occurs, the machine stop automatically.ZPW21 is designed to meet GMP standard.
The pressing area of an improved type of ZPW21 is sealed with four polymethyl methacrylate doors to be isolated with outside environment.
The parts contacting the materials are made of stainless steel or their surface is well antisepticized to avoid pollution.

Technical parameter of ZPW-21 Three Layer Press Machine

Dies (sets) 21 23
Max. Pressure (KN) 100 100
Max. dia. of tablet (mm) 45 45
Max. Thickness of largest tablet (mm) 12 12
Max. Depth of fill (mm) 25 25
Max. production capacity(pcs/h) 21000 22000
Rotational diameter(mm) 445 445
Rotational speed of revolving table(r/min) 10-25 10-25
Diameter of middle mould (mm) 45 45
Highness of middle mould(mm) 30 30
Length of up and low punch pole (mm) 32 32
Length of the upper punch pole (mm) 175 175
Length of the lower punch pole(mm) 180 180
Overall dimensions(mm) 1000*1250*1900 1000*1250*91900
Net Weight (kg) 3200 3200
Motor model YU132M4A YU132M4A
Motor(KW) 7.5 7.5

ZPW21 Dual Layer Pill Tablet Press Machine For Vitamin C Effervescent PillZPW21 Dual Layer Pill Tablet Press Machine For Vitamin C Effervescent PillZPW21 Dual Layer Pill Tablet Press Machine For Vitamin C Effervescent Pill

Packaging & Shipping

ZPW21 Dual Layer Pill Tablet Press Machine For Vitamin C Effervescent Pill

Export standard plywood package are supplied with well packed. We can make the packages according to customer's request. Sea packages or Air packages are both available.

Usually shipped special tablet press machine ZPW21 ZPW23 by sea.

Our Services

One station service to make sure our customer get good products and good service.

(1) Professional advice and rich experience help to choose machine.

(2) Warranty time: All machines are guaranteed for one year.

(3) Any problem: If you have any questions or any demands, we will reply you within 24 hours

except the special reasons once you enquiry us.

(4) Additives: installation book, Manual book, tool box will be sent with machine.

Product Quality

All products are guaranteed for one year, if any problems happen in guarantee period, our company will maintain for free.

Spare Part Replacement

First round mold punch die set for free, discount if more order.

Technical Service

We can provide design, installation and debugging services or remote maintenance teaching.

Delivery The Cargo To Nearest Port

We will arrange the shipment and delivery the cargo to your nearest port, save time and cost.

Detail Product Information

Provide picture, video, instruction and product brochure.

Reply Timely

24 hours hot line ,we will reply email within 12 hours.

FAQ

1. What about your machine quality?
Our factory has more than 30 years experience in mechanical processing; all our machines already get ISO9001, SGS certificate, CE certificate; already exported to many countries and areas; already got customer’s good reputation.


2. What about your machine price?
Anytime we will garanteen quality first, no matter price is good or not for us. Quality is first, on the top quality basis, of coursse you will get reasonable and satisfied price!


3. How can you ensure the machines' quality after we put the order?
Before the delivery, we will send you machines' pictures and videos, or you can come to our factory to make the quality checking by yourself, or by the third party inspection organization that contacted by your side.
