DIN 17175 15Mo3 Alloy Seamless Steel Pipe / Tubes Of Heat Resistant Steels
DIN 17175 15Mo3 Alloy Seamless Steel Pipe / Tubes Of Heat Resistant Steels
DIN 17175 15Mo3 Alloy Seamless Steel Pipe / Tubes Of Heat Resistant Steels
DIN 17175 15Mo3 Alloy Seamless Steel Pipe / Tubes Of Heat Resistant Steels
Specifications
Brand Name :
BaoYang
Model Number :
DIN 17175 15Mo3
Certification :
CE & ISO
Place of Origin :
cangzhou
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Delivery Time :
7~30 working days
Packaging Details :
Standard Export Packing
Name :
Seamless Alloy Steel Pipes
Process :
Hot Rolled Cold Rolled Cold Drawn
Standards :
DIN 17175 15Mo3
Material :
Alloy Steel Pipe
Wall Thickness :
1-30mm (0.04 Inch - 0.78 Inch)
Outer Diameter :
10-324mm
Processing Service :
Bending, Punching, Cutting
Usage :
Pipeline Transport, Oil/Gas Drilling, Machinery Industry
Description

DIN 17175 15Mo3 Alloy Seamless Steel Pipe/Tubes

1. Product Description: DIN 17175 15Mo3 Alloy Seamless Steel Pipe/Tubes are engineered for applications that demand high levels of heat resistance and mechanical strength. These pipes and tubes are manufactured from an alloy steel that is seamless, ensuring uniform wall thickness and superior structural integrity. The 15Mo3 grade is specifically designed to offer excellent creep resistance and good weldability, making it suitable for high-temperature applications.

2. Product Parameters:

Parameter Description
Grade DIN 17175 15Mo3
Material Alloy Steel (Seamless)
Standard DIN 17175
Size Range Various diameters and wall thicknesses as per DIN 17175
Length Standard lengths, customizable upon request
Ends Plain ends, beveled ends, threaded, or socket-weld ends
Surface Treatment As-rolled, annealed, or normalized

3. Mechanical Properties:

Property Typical Requirements
Tensile Strength ≥410 MPa (59,500 psi)
Yield Strength ≥255 MPa (37,000 psi)
Elongation ≥20% in 50 mm (2 in) or 4D, whichever is greater
Hardness Varies depending on heat treatment

4. Chemical Composition:

Element Typical Range (%)
Carbon 0.12 - 0.20
Manganese ≤1.00
Phosphorus ≤0.025
Sulfur ≤0.025
Silicon ≤0.50
Chromium ≤0.50
Molybdenum ≤0.50

5. Product Applications:

  • Boiler Tubes: Used for steam generation in high-pressure boilers.
  • Heat Exchangers: Ideal for use in heat exchangers operating under high pressure and temperature.
  • Superheater Tubes: Employed in superheater sections to raise steam temperature.
  • Pressure Vessels: Suitable for construction of high-pressure vessels and reactors.
  • Gas and Oil Industry: Utilized in pipelines and equipment for oil and natural gas transport in high-temperature environments.

DIN 17175 15Mo3 Alloy Seamless Steel Pipe / Tubes Of Heat Resistant SteelsDIN 17175 15Mo3 Alloy Seamless Steel Pipe / Tubes Of Heat Resistant Steels
