Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
Specifications
Brand Name :
BHY
Model Number :
SFM0612P
Certification :
ISO 9001:2008, CE, CU-TR, ISO14001:2004,OHSAS 18001:2007
Place of Origin :
Suzhou, China
MOQ :
1 set
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
800 sets/year
Delivery Time :
10-15 work days
Packaging Details :
Aluminum case, wooden case or metal packing case
Model :
SFM0612P
Drive Mode :
Pneumatic
Dimension :
1000*990*305mm
Net weight :
45kg
Feed :
0.08mm/r
Package :
Aluminum alloy, metal packing case or wooden box
Working Range :
6in - 12in (168.3-323.9mm)
Wall Thinkness. :
≤40mm
Description

Pneumatic Pipe Cutting and Beveling Machine For Energy Field

Product Introduction

SFM series equipment is one removable, portable, burr-free, highly-precise and vertical cold working pipe cutting and beveling equipment which can be used to process the pipe, install the bridge rail and repair the end surface of flange. It is the best choice for the outdoor construction!

Structure

Lighter, Small Gap, Split Type, Cutting & Beveling

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

Industry Application
The SFM Series of Pipe Cutting and Beveling Machines are widely used in long-distance transport pipeline, power plant, nuclear power, petroleum, chemical engineering, natural gas, boiler shop, pharmacy, pipe prefabrication plant, pipeline installation engineering, rush-repair work, etc. Our products play an important role in these fields.

Specifications

Model SFM0612
Drive Mode Pneumatic
Air Requirements 2-3m³/min
Application Range (O.D.) 6" - 12" (168.3-323.9mm)
Wall Thickness ≤40mm
Net Weight 45kg
Feed Method Star wheel system
Feed 0.08mm/r
All standard accessories included

Specification

■ Drive Options: Pneumatic, Hydraulic, and Electric

■ Air requirements: 2-3m³/min

■ Hydraulic requirements: 65L/min,10MPa (15.8GPM,1500PSI)

■ Electric requirements: 220V/AC 50/60Hz
■ Feed mode: Star wheel, automatically
■ Feed rate: Fixed@0.08mm per circle
■ Used for pipe material: carbon steel, alloy steel, stainless steel, duples stainless steel, nickel alloy

Beveling type

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

SFM Tools

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

Models

Model

Processing

range (in)

Max wall

thickness (mm)

 Weight(kg) Drive mode
SFM0206 2"~ 6" 30 35

Pneumatic

Hydraulic

Electric
SFM0408 4"~ 8" 40 40
SFM0612 6"~12" 80 45
SFM0814 8"~14" 100 55
SFM1218 12"~18" 100 70
SFM1420 14"~20" 100 76

Electric

Hydraulic
SFM1824 18"~24" 100 123
SFM2026 20"~26" 100 130
SFM2430 24"~30" 100 142
SFM2632 26"~32" 100 150
SFM3036 30"~36" 100 159
SFM3642 36"~42" 100 179
SFM4248 42"~48" 100 198
SFM4860 48"~60" 100 642
SFM6072 60"~72" 100 730
SFM7284 72"~84" 100 820

* Processing range can be customized according to the pipe diameter.

Manufacture

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD MountedPneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD MountedPneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted

Working On Site

Pneumatic Pipe Cutting and Beveling Machine For Energy Field, 6in - 12in, 12in - 18in, OD Mounted
