DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230
Specifications
Brand Name :
BHY
Model Number :
DWS1230
Certification :
ISO 9001:2008, CE, CU-TR, ISO14001:2004,OHSAS 18001:2007
Place of Origin :
Suzhou, China
MOQ :
1PC
Price :
Please Consult
Supply Ability :
10 PC/Year
Delivery Time :
180 days
Packaging Details :
Fitted Storage Case
Name :
Subsea Diamond Wire Saw
Model :
DWS1230
Minimum Size (OD) :
12in (305mm)
Maximum Size (OD) :
30in (762mm)
Drive Options :
Hydraulic Driven
Cutting Wire Speed :
Variable, 0-1,500 RPM
Power Requirements :
20 GPM @ 2500 PSI (76 LPM @ 172 BAR)
Description

Product Description

BHY Reliable On-site Machining Solutions
Website: http://www.pipecuttingbevelingmachine.com/buy-Diamond_Wire_Saw.html​

Subsea Diamond Wire Saw

DN300-750 Subsea Diamond Wire Saw, Pipe Concrete Cutting Machine - DWS1230


★ Introduction:
Bohyar is the first company in China to achieve R&D of Diamond Wire Saw.The Bohyar Subsea Diamond Wire Saws are designed for underwater cutting of horizontal or vertical pipe, casings and structure, with five models that cut from 4in to 84in O.D.Running on hydraulic power, the wire saw is controlled remotely using the Control Panel or ROV control operable via zero leak hot stabs.
Bohyar Diamond Wire Saws feature a unique hydrodynamic design that dramatically reduces centrifugal forces during operation, which means less power wasted in churning water and more power directed to cutting the workpiece.

★ Technical Parameters
Model DWS 0416 DWS 1230 DWS 1636 DWS 3052 DWS 6084
Maximum
Pipe Capacity		 16in (406mm) 30in (762mm) 36in (914mm) 52in (1321mm) 84in (2134mm)
Minimum
Pipe Capacity		 4in (100mm) 12in (305mm) 16in (406mm) 30in (762mm) 60in (1524mm)
Height 55in (1397mm) 82.5in (2096mm) 92.5in (2350mm) 127in (3226mm) 205in (5207mm)
Width 44in (1118mm) 63.75in (1619mm) 69.75in (1772mm) 87.25in (2216mm) 118.8in (3017mm)
Depth 28in (711mm) 30in (762mm) 32in (813mm) 43in (1092mm) 43in (1092mm)
Weight 730lbs (331kg) 1000lbs (454kg) 1200lbs (544kg) 1600lbs (726kg) -
★ Product Features:
•Lightweight aluminum plate construction.
•Five models cut from 4in to 84in O.D.(DN100-2100).
•Easily replaceable long life diamond wire cutting element.
•Hydraulically operated synchronized clamping arms.
•Self-regulating Tensioning System,Spring and cylinder can maintain a constant tension of the diamond rope, which effectively prevent excessive tension causing damage to the machine, enhance the safety of the operator and greatly extend the rope life.
•Synchronous Clamping to reduce the visual error, and ensure the uniformity of the force.
•Compressible Cutting to reduce the influence of moving or shifting slightly during the operation
•Overload clutch for bow damage prevention.
•Corrosion resistant with anode protection.
•Mounts vertically or horizontally.

★ Product Advantages:
•Lightweight planetary feed drive.
•Large diameter high contact area wire drive wheels.
•Hydraulic wire drive motor w/overhung bearing support.
•Lift interfaces for vertical or horizontal deployment.
•Lightweight aluminum plate construction.
•User replaceable clamp contact pads and wheel inserts.

BHY-Reliable On-site Machining Solutions
No. 28Datong Road, Suzhou New District, PR China
Website: www.bohyarglobal.com
