Sand Pump Dredger Suction Pipeline Dredging Black Uhmwpe Tubing Diameter Large
Sand Pump Dredger Suction Pipeline Dredging Black Uhmwpe Tubing Diameter Large
Sand Pump Dredger Suction Pipeline Dredging Black Uhmwpe Tubing Diameter Large
Sand Pump Dredger Suction Pipeline Dredging Black Uhmwpe Tubing Diameter Large
Sand Pump Dredger Suction Pipeline Dredging Black Uhmwpe Tubing Diameter Large
Sand Pump Dredger Suction Pipeline Dredging Black Uhmwpe Tubing Diameter Large
Specifications
Brand Name :
JiuBei
Certification :
ISO
Place of Origin :
China
MOQ :
100m
Price :
usd50-500/m
Payment Terms :
L/C, T/T
Supply Ability :
3000m/month
Delivery Time :
7working days
Packaging Details :
Standard sea worthy packaging
Name :
UHMWPE lined steel pipe
Material :
Carbon steel and UHMWPE
Color :
As request
Dimension :
DN90~1200mm
Installation :
Steel flange
Warranty :
12months
Thickness :
4~50mm
Alloy or not :
yes
Outer diameter(round) :
90-1200mm
Application :
Mine tailing discharging
Description

Large Diameter Black UHMWPE Pipe für Sand Pump, Sand Pump Suction UHMWPE Pipe



Ultra high molecular weight polyethylene (UHMWPE) pipe is a thermoplastic plastic pipe with a viscosity molecular weight greater than 2.5 million. Dubbed “miracle plastic,” UHMWPE is the new star of the material. It will represent an energetic life and play an important role in many areas.
Main Features:
1.Extremely high abrasion resistance;
2. Very high impact resistance;
3. good self-lubrication;
4. Getting dirty is not easy;
5. Good corrosion resistance;
6High tensile and breaking strength;
7. Excellent resistance to low temperatures;
8. long duration;
9. Easy installation.
Areas of application:
1.For transporting sand, mud and river, port, seawater dredging sludge;
2. For transporting tailings and sludges in metallurgical mines and mining;
3. Transport of fine coal and coal ash to combined heat and power plants and power plants
4. Transport of fine coal and coal water sludge from coal processing plants of the hard coal industry;
5. For transporting sludges and corrosive, slag-containing liquids in the chemical industry;
6For the transportation of crude oil, oil and food.

O.D.

DN(mm)

0.4MPa0.6MPa0.8MPa1MPa1.25MPa1.65MPa2.0MPa

Thickness

mm

Thickness

mm

Thickness

mm

Thickness

mm

Thickness

mm

Thickness

mm

Thickness

mm
110 4.76.07.49.211.4
125 5.46.78.310.312.7
140 6.07.79.511.814.6
160 5.26.98.610.713.316.4
180 5.97.79.611.914.718.2
219 6.58.610.813.416.620.5
2254.97.39.711.914.818.422.7
2505.58.110.713.416.620.625.4
2806.29.112.015.018.723.228.6
3156.910.213.516.921.126.132.2
3507.811.515.319.123.729.436.3
4008.813.017.221.526.733.140.9
4509.814.619.113.929.736.8
50011.016.221.426.733.241.2
56012.318.224.130.037.4
63013.820.527.233.942.1
70015.322.730.638.1
80018.026.038.1
90020.030.042.1
100022.033.0


Detail images:
Sand Pump Dredger Suction Pipeline Dredging Black Uhmwpe Tubing Diameter LargeSand Pump Dredger Suction Pipeline Dredging Black Uhmwpe Tubing Diameter Large
