Standard

JIS G3141,DIN1623,EN10130

Thickness

0.15-6.0mm(Aluminum sheet) 6.0-25.0mm(Aluminum plate)

Temper

H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc.

Surface Treatment

Mill Finished, Anodized, Embossed, PVC Coated, etc

Alloy

Application field

1xxx

1050

Insulation, food industry, decoration, lamp, traffic signs, etc.

1060

Fan blade, Lamps and lanterns, Capacitor shell, Auto parts, Welding parts.

1070

Capacitor, Rear panel of vehicle refrigerator, charging point, heat sink, etc

1100

Cooker, building material, printing, heat exchanger, bottle cap, etc

2xxx

2A12

Aircraft structures, rivets, aviation, machinery, missile components, the card wheel hub, propeller components, aerospace parts, car parts, and various other structural parts.

2024

3xxx

3003

Aluminum curtain wall panel, aluminum Ceiling, Electric cooker bottom, TV LCD backboard, storage tank, curtain wall, building construction panel heat sink, billboard. Industrial floor, air conditioning, refrigerators radiators, Make-up board, Prefabricated house, etc.

3004

3005

3105

5xxx

5052

Marine and transportation material, railway carriage's inner and outer cabinet, oil and chemical industry storage device, equipment and medical device panel, etc.

5005

Marine applications, bodies of boats, buses, trucks and trailers. Curtain wall panel.

5086

Ship board, deck, bottom and edge panel, etc.

5083

Tanker, oil storage tank, drilling platform, ship board, deck, bottom, welded parts and edge panel, railway carriage's board, automotive and aircraft panel, cooling device and automotive molding, etc.

5182

Tanker body, marine facilities, pressure container, transportation, etc.

5454

5754

6xxx

6061

Railway inside and outside parts, board and bed plate. Industry molding
Highly stressed applications include Roofing construction, transportation, and marine as well as mould.

6083

6082

6063

Auto parts, architectural fabrication, window and door frames, aluminum furniture, electronic components as well as various consumer durable products.

7xxx

7005

Truss, rod/bar and the container in transportation vehicles; Large-sized heat exchangers.

7050

Molding (bottles) mode, ultrasonic plastic welding mold, golf head, shoe mold, paper and plastic molding, foam molding, lost wax mold, templates, fixtures, machinery and equipment.

7075

The aerospace industry, military industry, electronics, etc.
